Каталог запасных частей к технике: Great Plains 3N-4010. Rear Axle Assembly
1
2
3
4
5
6
7
8
9
9
10
10
11
11
11
11
12
13
14
15
15
16
17
18
19
19
20
20
21
21
22
23
23
24
24
25
26
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
48
49
49
50
50
51
51
51
51
52
52
52
52
53
54
55
56
57
58
59
59
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 196-106H | 40P REAR AXLE WLDMT | |
| 2 | 802-010C | HHCS | |
| 3 | 804-009C | WASHER LOCK SPRING | |
| 4 | 502-068D | HYD HOSE CLAMP BRACKET | |
| 5 | 803-073C | NUT HEX 1 1/2-6 PLT | |
| 6 | 804-197C | WASHER LOCK 1 1/2 PLT | |
| 7 | 803-063C | NUT HEX JAM 1 1/2-6 PLT | |
| 8 | 196-293H | EYEBOLT WELDMENT | |
| 9 | 890-011C | BUSHING SPINDLE | |
| 10 | 810-498C | CYL REP 4.5X16X1.5 ROD (TIE) | |
| 11 | 800-001C | GREASE ZERK STRAIGHT | |
| 12 | 196-292H | CYL LOCK CHANNEL 1 1/2X17 3/4 | |
| 13 | 805-001C | PIN 3/8 X 3 USABLE LW/PIN | |
| 14 | 196-652D | 40P TOOLBAR PIVOT PIN | |
| 15 | 802-728C | HHCS 1-8X18 GR5 | |
| 16 | 196-774D | PIVOT PIN RETAINER WASHER | |
| 17 | 804-035C | WASHER FLAT | |
| 18 | 803-079C | NUT HEX SLOTTED | |
| 19 | 196-654D | 40P CASTER INNER PIVOT TUBE | |
| 20 | 804-027C | WASHER LOCK SPRING 1 PLT | |
| 21 | 803-031C | NUT HEX | |
| 22 | 196-287H | 40P CASTER PARALLEL ARM WLDMT | |
| 23 | 890-666C | BUSHING 1 7/8X1 5/8X1 1/2 SPLT | |
| 24 | 804-029C | WASHER FLAT | |
| 25 | 802-034C | HHCS | |
| 26 | 804-015C | WASHER LOCK SPRING | |
| 27 | 161-231D | NTA CASTER RETAINER CAP | |
| 28 | 890-193C | STEEL BUSHING | |
| 29 | 196-329H | 40P CASTER SUPPORT WLDMT | |
| 30 | 804-102C | PIVOT THRUST WASHER | |
| 31 | 196-397H | REAR CASTER SUPT WLDMT | |
| 32 | 196-273K | LH TIRE/RIM 395/55B16.5 SKID 8 | |
| 33 | 802-069C | HHCS 3/4-10X5 GR5 | |
| 34 | 803-025C | NUT HEX 3/4-10 PLT NYLOCK | |
| 35 | 815-103C | HUB AND SPINDLE ASY 8 BOLT 5790# | |
| 36 | 196-272K | RH TIRE/RIM 395/55B16.5 SKID 8 | |
| 37 | 196-294H | 40P RADAR MOUNT WLDMT | |
| 38 | 196-769D | CASTER SPRING PLUNGER | |
| 39 | 807-143C | SPRING COMP 1.88OD x .362W | |
| 40 | 196-770D | CASTER DETENT PIN | |
| 41 | 802-064C | HHCS 3/4-10X2 GR5 | |
| 42 | 804-023C | WASHER LOCK SPRING | |
| 43 | 803-027C | NUT HEX | |
| 44 | 802-070C | HHCS 3/4-10X6 GR5 | |
| 45 | 803-026C | NUT LOCK | |
| 46 | 805-085C | PIN COTTER | |
| 47 | 802-067C | HHCS 3/4-10X4 GR5 FTHD | |
| 48 | 196-775D | SPACER WASHER | |
| 49 | 196-393H | RPBY 196-409H | |
| 50 | 196-392H | CYL PIN NR 1.25X3.63USBX3.13CH | |
| 51 | 804-028C | WASHER FLAT 1 USS PLT | |
| 52 | 805-105C | PIN COTTER 1/4 X 2 1/2 PLT | |
| 53 | 802-300C | HHCS 1/4-28X3/8 GR5 | |
| 54 | 803-048C | NUT HEX JAM 3/4-10 PLT | |
| 55 | 802-128C | HHCS 1/2-13X2 GR5 | |
| 56 | 196-870D | REAR CASTER LOCK PLT HARDENED | |
| 57 | 803-020C | NUT HEX | |
| 58 | 196-394L | REAR CASTER AND HARD LCK PLT KIT | |
| 59 | 890-800C | BUSHING 4.0X3.5X3.0 LONG SPLIT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
