Каталог запасных частей к технике: Lemken Variopack 110FEPK700. Basic frame FEP-K 700 B
1
2
3
4
5
6
6
7
8
9
10
11
12
14
15
15
16
17
18
20
21
23
23
23
23
24
25
26
28
28
29
30
31
33
34
36
38
39
40
41
42
43
44
45
45
46
47
48
50
51
52
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 301 3263 | Bolt | |
| 2 | 301 3838 | Bolt | |
| 3 | 301 4349 | Bolt | |
| 4 | 303 0258 | Castle nut | |
| 5 | 303 0933 | Selflocking nut | |
| 6 | 303 0935 | Selflocking nut | |
| 7 | 303 0936 | Selflocking nut | |
| 8 | 305 6133 | Washer | |
| 9 | 305 2072 | Shim | |
| 10 | 309 6051 | Expansion bush | |
| 11 | 305 2155 | Shim | |
| 12 | 305 6283 | Washer | |
| 14 | 305 8877 | Securing ring | |
| 15 | 309 3338 | Expansion bush | |
| 16 | 309 6038 | Expansion bush | |
| 17 | 313 5033 | Pin with stop | |
| 18 | 303 0343 | Grooved nut | |
| 20 | 313 8136 | Pin with grip | |
| 21 | 313 8239 | Pin | |
| 23 | 317 3417 | Expansion bush | |
| 24 | 323 0032 | Seal washer | |
| 25 | 323 6348 | Grease nipple | |
| 26 | 323 7605 | Felt ring with housing | |
| 28 | 421 0688 | Hub | |
| 29 | 421 5299 | Center section | |
| 30 | 421 5296 | Lateral part | |
| 31 | 421 5297 | Lateral part | |
| 33 | 421 5305 | Hook | |
| 34 | 421 5306 | Lever | |
| 36 | 429 2811 | Stand | |
| 38 | 317 3433 | Expansion bush | |
| 39 | 309 6172 | Expansion bush | |
| 40 | 313 7911 | Top link pin with chain | |
| 41 | 329 6151 | Cup spring | |
| 42 | 317 8675 | Adjusting ring | |
| 43 | 319 9216 | Bearing | |
| 44 | 323 0035 | Seal washer | |
| 45 | 323 0214 | Seal washer | |
| 46 | 323 7850 | Felt ring | |
| 47 | 323 7852 | Felt ring | |
| 48 | 329 8106 | Spring | |
| 50 | 421 0530 | Axle | |
| 51 | 421 1595 | Flat steel | |
| 52 | 421 5312 | Link | |
| 53 | 421 5313 | Lower link connection |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
