Каталог запасных частей к технике: Great Plains NP4000-1630. Lift Assist Assembly
1
1
2
3
4
4
5
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
35
36
37
38
39
40
41
42
43
44
45
46
46
47
47
48
48
49
50
51
52
53
54
55
56
57
58
59
60
61
61
62
63
64
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 803-032С | NUT HEX JAM 1 1/4-7 PLT | |
| 2 | 407-277Н | HOSE LOOP W/ TAB | |
| 3 | 804-030С | WASHER LOCK 1 1/4 SPRING PLT | |
| 4 | 407-878Н | LH LIFT ASSIST PVT WLDMNT | |
| 4 | 407-879Н | RH LIFT ASSIST PVT WLDMNT | |
| 5 | 802-728С | HHCS 1-8X18 GR5 | |
| 6 | 818-437С | DECAL WARNING HIGH PRESSUR LRG | |
| 7 | 803-034С | NUT HEX 1 1/4-7 PLT | |
| 8 | 196-142Н | EYEBOLT WELDMENT | |
| 9 | 890-005С | BUSHING CYL 1 1/4 X 1 X 1 | |
| 10 | 804-029С | WASHER FLAT 1 SAE | |
| 11 | 804-027С | WASHER LOCK SPRING 1 PLT | |
| 12 | 803-031С | NUT HEX 1-8 PLT | |
| 13 | 196-654D | 40P CASTER INNER PIVOT TUBE | |
| 14 | 800-001С | GREASE ZERK STRAIGHT 1/4-28 | |
| 15 | 402-172Н | 16R PARALLEL ARM WLDMNT 2 | |
| 16 | 890-666С | BUSHING 1 7/8X1 5/8X1 1/2 SPLT | |
| 17 | 802-034С | HHCS 1/2-13X1 1/4 GR5 | |
| 18 | 804-015С | WASHER LOCK SPRING 1/2 PLT | |
| 19 | 161-231D | NTA CASTER RETAINER CAP | |
| 20 | 407-462D | CASTER VERT SHAFT | |
| 21 | 407-281Н | CYLINDER LOCK CHANNEL 1 1/2 X | |
| 22 | 805-001С | PIN 3/8 X 3 USABLE LW/PIN | |
| 23 | 407-747Н | WIDE LA LOWER LINK WLDMT | |
| 24 | 890-193С | STEEL BUSHING 3 1/4X3IDX3LONG | |
| 25 | 802-067С | HHCS 3/4-10X4 GR5 FTHD | |
| 26 | 803-048С | NUT HEX JAM 3/4-10 PLT | |
| 27 | 838-380С | DECAL CAUTION TRANSP. LOCK | |
| 28 | 266-012D | PLATE RND 3/16" THK 1 7/8" DIA | |
| 29 | 807-143С | SPRING COMP 1.88OD x .362W | |
| 30 | 266-020D | UHMW RND 2.0 DIA X 2.0 LONG | |
| 31 | 804-102С | PIVOT THRUST WASHER | |
| 32 | 803-027С | NUT HEX 3/4-10 PLT | |
| 33 | 804-023С | WASHER LOCK SPRING 3/4 PLT | |
| 34 | 802-469С | HHCS 3/4-10X8 GR5 PLT | |
| 35 | 407-742Н | NP4000 CASTR FRM WLDMT WIDE | |
| 35 | 417-407Н | NP4000 CASTER FRAME GEN2 | |
| 36 | 802-023С | HHCS 3/8-16X1 3/4 GR5 | |
| 37 | 407-743Н | NP4000 LA AXLE WLDMT | |
| 38 | 407-865D | NP4000 AXLE SPACER | |
| 39 | 803-01ЗС | NUT LOCK 3/8-16 PLT | |
| 40 | 407-866D | NP4000 AXLE SPACER LONG | |
| 41 | 804-205С | WASHER MACH 2 1/2X1 3/4X10GA | |
| 42 | 803-239С | NUT HEX SLOTTED 1 1/2-12 PLT | |
| 43 | 805-105С | PIN COTTER 1/4 X 2 1/2 PLT | |
| 44 | 848-801С | DECAL CAUTION TIRE 80PSI /300 | |
| 45 | 802-182С | HUB STUD 5/8-18X2 1/2 GR5 | |
| 46 | 816-359С | SEAL 3.375X2.250X.438 CR 22532 | |
| 47 | 822-144С | BRG CONE 1.75ID 25580 | |
| 48 | 802-01 ЗС | HHCS 5/16-18X1 3/4 GR5 | |
| 49 | 800-058С | GREASE ZERK 1/4-28 X 45-DEG | |
| 50 | 803-089С | NUT HEX FLANGE 5/8-18 PLT | |
| 51 | HDA820 | CTD HD820 HUB | |
| 52 | 815-377С | HUB ASSY 8 BLT 6" PILOT | |
| 53 | 814-210С | VALVE STEM METAL TR-575 TUBLES | |
| 54 | 814-406С | RIM 17.5X10.5 8-8 BLT 6" PILOT | |
| 55 | 814-405С | TIRE SKID ST 14-17.5NHS 14 PLY | |
| 56 | 814-407С | TIRE/WHEEL 14-17.5NHS 14PLY | |
| 57 | 810-723С | CYL 3X10X1 1/4 | |
| 58 | 810-442С | MW STOP BUSH SET 1 1/4 SBS125 | |
| 59 | 2А0134 | MW COTTER PIN | |
| 60 | 805-124С | PIN CLEVIS 1 X 3 11/16 GR5 PLT | |
| 61 | 804-028С | WASHER FLAT 1 USS PLT | |
| 62 | 417-104D | PIN CLEVIS 1 X 9.25 USEABLE | |
| 63 | 805-027С | PIN ROOL 5/16 X 1 1/2 PLT | |
| 64 | 816-813С | HOSE WRAP 3-4.5 X 12LG VELCR |
