Каталог запасных частей к технике: Lemken Zirkon 10/500K. Zirkon 10/500 K
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
5
5
6
6
6
6
6
7
7
7
8
8
8
9
9
9
9
9
9
9
10
10
10
10
10
10
11
11
11
11
11
11
11
11
11
11
11
12
12
12
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 608 9094 | Unlocking device | |
| 1 | 682 2490 | Support | |
| 1 | 661 1379 | Lower link connection | |
| 1 | 661 1378 | Lower link connection | |
| 1 | 661 1375 | Lower link connection | |
| 1 | 640 8406 | Headstock | |
| 1 | 640 1136 | Extension for headstock | |
| 1 | 640 1134 | Extension for headstock | |
| 1 | 608 9151 | Basic frame | |
| 1 | 608 9097 | Unlocking device electr.magne. | |
| 1 | 608 9095 | Unlocking device electr.magne. | |
| 2 | 666 1141 | Blade tine | |
| 2 | 666 1140 | Blade tine | |
| 2 | 608 8669 | Gear bed | |
| 2 | 608 8668 | Gear bed | |
| 2 | 608 7815 | Holder for levelling bar | |
| 2 | 608 7809 | Holder for levelling bar | |
| 2 | 608 6556 | Levelling bar, front | |
| 2 | 608 6542 | Levelling bar | |
| 2 | 608 6084 | Frame carrier | |
| 4 | 655 9533 | Miter gear | |
| 4 | 655 9532 | Miter gear | |
| 4 | 655 9531 | Gear box | |
| 4 | 555 9533 | Miter gear | |
| 4 | 555 9532 | Miter gear | |
| 4 | 555 9531 | Gear box | |
| 5 | 622 6765 | Trapeze disc roller | |
| 5 | 622 6759 | Trapeze packer roller | |
| 5 | 622 6758 | Trapeze packer roller | |
| 5 | 622 6751 | Trapeze packer roller | |
| 5 | 622 6743 | Packer roller, short scraper | |
| 5 | 622 6738 | Trapeze packer roller | |
| 5 | 622 6727 | Trapezering roller | |
| 5 | 622 6354 | Tube bar roller | |
| 5 | 622 6340 | Packer roller | |
| 5 | 622 2892 | Carrier | |
| 5 | 622 2890 | Carrier | |
| 5 | 622 0244 | Adjuster | |
| 6 | 657 2435 | Feeding disc | |
| 6 | 657 2434 | Feeding disc | |
| 6 | 608 4021 | Stroke | |
| 6 | 608 4009 | Side plate | |
| 6 | 608 3956 | Side plate extension | |
| 7 | 661 8458 | Hydraulic lift linkage | |
| 7 | 661 8476 | Front headstock | |
| 7 | 661 8524 | Fittings | |
| 8 | 682 1329 | Track marker | |
| 8 | 682 1272 | Intermediate bracket | |
| 8 | 582 1248 | Axle for track marker | |
| 9 | 657 4998 | Track scraper with holder | |
| 9 | 657 4990 | Track scraper with holder | |
| 9 | 657 4989 | Track scraper with holder long | |
| 9 | 557 5001 | Track scraper | |
| 9 | 557 4995 | Track scraper | |
| 9 | 557 2528 | Holder for track scraper | |
| 9 | 557 2520 | Holder for track scraper | |
| 10 | 670 5071 | Transport protection | |
| 10 | 670 5070 | Transport protection | |
| 10 | 670 2014 | Lighting equipment with boards | |
| 10 | 670 2003 | Lighting equipment, front | |
| 10 | 670 1646 | Carrier for light | |
| 10 | 670 1645 | Carrier for light | |
| 11 | 673 4477 | PTO shaft control, audible | |
| 11 | 673 4472 | PTO shaft control, audible | |
| 11 | 670 5237 | PTO guard | |
| 11 | 670 5236 | PTO guard | |
| 11 | 670 5055 | PTO guard | |
| 11 | 655 7310 | PTO shaft | |
| 11 | 655 7309 | PTO shaft P600-710 | |
| 11 | 655 7308 | PTO shaft P600-710 | |
| 11 | 655 7307 | PTO shaft P600-710 | |
| 11 | 655 7306 | PTO shaft P600-710 | |
| 11 | 655 7136 | PTO shaft | |
| 12 | 675 5208 | Hydraulic assembly DA | |
| 12 | 675 5222 | HY-assembly folding device | |
| 12 | 675 8406 | HY-assembly track marker |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
