Каталог запасных частей к технике: Lemken Solitair 9/500KA. Solitair 9/500 KA > 263550
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 573 8060 | Electric drive | |
| 1 | 682 5766 | Dosage | |
| 1 | 682 5758 | Dosage | |
| 1 | 682 5575 | Cover | |
| 1 | 682 5572 | Cover | |
| 1 | 682 5571 | Cover | |
| 1 | 682 5340 | Hopper | |
| 1 | 682 5312 | Hopper | |
| 1 | 682 5308 | Hopper | |
| 1 | 582 5892 | Seeding mechanism | |
| 1 | 582 5768 | Dosage, lower part | |
| 1 | 582 5766 | Dosage, top part | |
| 1 | 582 5586 | Support | |
| 2 | 682 5055 | Tramline mechanism | |
| 2 | 682 5068 | Distributor | |
| 2 | 682 5069 | Distributor | |
| 2 | 682 5070 | Distributor | |
| 2 | 682 5109 | Supply hoses | |
| 2 | 699 0820 | Recirculation | |
| 2 | 682 5054 | Tramline mechanism | |
| 2 | 682 5033 | Emptying unit for hopper | |
| 2 | 582 5229 | Flexible hose | |
| 2 | 582 5231 | Flexible hose | |
| 2 | 682 2504 | Holder for distributor | |
| 2 | 682 2505 | Holder for distributor | |
| 2 | 682 5030 | Emptying unit for hopper | |
| 2 | 682 5032 | Emptying unit for hopper | |
| 3 | 682 5672 | Cyclone | |
| 3 | 682 5680 | Fan | |
| 4 | 682 7113 | Adjustment centre | |
| 4 | 682 7112 | Adjustment centre | |
| 4 | 682 7110 | Adjustment centre | |
| 4 | 682 7109 | Adjustment centre | |
| 4 | 682 7103 | Adjustment centre | |
| 4 | 682 7101 | Adjustment centre | |
| 4 | 682 7001 | Basic frame | |
| 5 | 682 3020 | Step with platform | |
| 5 | 682 3019 | Step with platform | |
| 5 | 682 3018 | Step with platform | |
| 5 | 682 3015 | Step with platform | |
| 5 | 682 3014 | Step with platform | |
| 5 | 682 3013 | Step with platform | |
| 5 | 682 3012 | Step with platform | |
| 5 | 682 3011 | Step with platform | |
| 6 | 682 8144 | Coulter frame | |
| 6 | 682 8142 | Coulter frame | |
| 6 | 682 8140 | Coulter frame | |
| 6 | 682 8046 | Coulter frame | |
| 6 | 682 8044 | Coulter frame | |
| 6 | 682 8042 | Coulter frame | |
| 7 | 682 2724 | Carrier | |
| 7 | 682 2730 | Holder, short | |
| 7 | 682 6032 | Double disc coulter + roller | |
| 7 | 682 6038 | Single disc coulter, long | |
| 7 | 682 6039 | Single disc coulter, short | |
| 7 | 682 6040 | Single disc coulter, short | |
| 7 | 682 6041 | Single disc coulter, long | |
| 7 | 682 6401 | Single harrow | |
| 7 | 682 2703 | Levelling harrow | |
| 7 | 682 2702 | Levelling harrow | |
| 7 | 582 6032 | Disc carrier | |
| 7 | 582 2702 | Levelling harrow | |
| 7 | 582 2703 | Levelling harrow | |
| 7 | 582 2704 | Levelling harrow | |
| 7 | 582 2727 | Swinging arm | |
| 7 | 582 6011 | Cover with scraper | |
| 7 | 582 6012 | Cover with hard metal scraper | |
| 7 | 582 6021 | Rocker arm | |
| 7 | 582 6028 | Disc | |
| 8 | 682 2729 | Holder, long | |
| 8 | 682 2616 | Pre-emergency marker | |
| 8 | 682 2615 | Pre-emergency marker | |
| 8 | 682 2614 | Pre-emergency marker | |
| 8 | 682 2604 | Pre-emergency marker | |
| 9 | 661 8364 | Fittings | |
| 9 | 661 8373 | Fittings | |
| 9 | 682 2490 | Support | |
| 10 | 670 2017 | Lighting equipment | |
| 10 | 670 2005 | Lighting equipment | |
| 10 | 670 2004 | Lighting equipment, front | |
| 10 | 570 2005 | Lighting equipment, rear | |
| 10 | 570 2004 | Lighting equipment, front | |
| 11 | 650 8572 | Trailer | |
| 11 | 650 8573 | Trailer | |
| 11 | 661 1330 | Lower link connection | |
| 11 | 661 1332 | Lower link connection | |
| 11 | 661 1336 | Lower link connection | |
| 11 | 661 1338 | Lower link connection | |
| 11 | 661 6020 | Carrier | |
| 11 | 640 9134 | Deichsel | |
| 11 | 550 8873 | Wheel 8/221/575 | |
| 11 | 550 8872 | Wheel 8/221/575 | |
| 11 | 550 8861 | Wheel 6/161/205 D18 | |
| 11 | 550 8860 | Wheel 6/161/205 D18 | |
| 11 | 550 8850 | Wheel 6/161/205 D18 | |
| 11 | 549 8897 | Bearing | |
| 11 | 549 8894 | Bearing | |
| 11 | 313 7880 | Top link pin, cpl. | |
| 12 | 629 7402 | Stand | |
| 12 | 629 4418 | Stand | |
| 12 | 629 4413 | Stand | |
| 13 | 657 4993 | Track scraper with holder | |
| 13 | 657 4991 | Track scraper with holder | |
| 13 | 657 2653 | Track scraper with holder | |
| 13 | 657 2650 | Track scraper with holder | |
| 13 | 557 4995 | Track scraper | |
| 13 | 557 4991 | Track scraper | |
| 13 | 557 2653 | Holder | |
| 13 | 557 2650 | Holder | |
| 14 | 682 1329 | Track marker | |
| 14 | 682 1272 | Intermediate bracket | |
| 14 | 682 1254 | Track marker | |
| 14 | 582 1248 | Axle for track marker | |
| 15 | 673 5030 | Electronic box | |
| 15 | 673 5027 | Cable form | |
| 15 | 673 5025 | On board computer | |
| 15 | 673 5024 | On board computer | |
| 15 | 673 5017 | Tractor mounting set | |
| 15 | 673 5015 | Tractor mounting set | |
| 15 | 673 4449 | Partly width switch off | |
| 16 | 675 4828 | Pump | |
| 16 | 675 4780 | Oil cooler | |
| 16 | 675 4200 | Oil tank | |
| 16 | 675 2147 | Relief pressure valve | |
| 16 | 575 2692 | HY-pipe assembly | |
| 16 | 575 2683 | HY-pipe assembly pole | |
| 16 | 555 4007 | Coupling | |
| 16 | 555 4006 | Coupling | |
| 16 | 555 4005 | Coupling | |
| 16 | 555 4001 | Coupling | |
| 17 | 682 2514 | Drive wheel | |
| 17 | 675 8406 | HY-assembly track marker | |
| 17 | 675 8401 | HY-assembly track marker | |
| 17 | 675 8302 | HY-assembly coulter frame | |
| 17 | 675 8251 | HY-assembly coulter lifting | |
| 17 | 675 8201 | Hydraulic assembly fan | |
| 18 | 682 2512 | Drive wheel |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
