Каталог запасных частей к технике: Lemken Solitair 12/5800SW. 68210469 Dosage
1
2
3
4
5
5
5
6
6
7
8
9
10
11
12
13
13
14
15
15
15
16
17
18
18
19
20
20
20
20
21
22
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 301 0139 | Threaded pin | |
| 2 | 301 5857 | Allen screw | |
| 3 | 301 7502 | Hexagon bolt | |
| 4 | 301 7505 | Saucer-head screw | |
| 5 | 301 7506 | Hexagon bolt | |
| 6 | 301 7512 | Hexagon bolt | |
| 7 | 301 9913 | Screw | |
| 8 | 303 0800 | Selflocking nut | |
| 9 | 303 0801 | Selflocking nut | |
| 10 | 303 0802 | Selflocking nut | |
| 11 | 305 6125 | Washer | |
| 12 | 305 8702 | Washer | |
| 13 | 305 9896 | Spring ring | |
| 14 | 305 9899 | Spring ring | |
| 15 | 30510066 | Washer | |
| 16 | 309 3460 | Expansion bush | |
| 17 | 323 8059 | Cap | |
| 18 | 325 1157 | Hose clip | |
| 19 | 373 4082 | Seal socket | |
| 20 | 37710087 | Flexible hose | |
| 21 | 39010035 | Label | |
| 22 | 482 5841 | Nozzle for seed housing | |
| 23 | 482 5842 | Restrictor | |
| 24 | 482 5850 | Calibration trough | |
| 25 | 482 5868 | Plate | |
| 26 | 482 5869 | Holder | |
| 27 | 482 5873 | Fixing device | |
| 28 | 482 5877 | Cover plate | |
| 29 | 482 5920 | Soil flap lever | |
| 30 | 482 5921 | Slide | |
| 31 | 482 5925 | Plate | |
| 32 | 48210031 | Dust cap | |
| 33 | 48210032 | Dust cap | |
| 34 | 573 4389 | Sensor | |
| 35 | 573 8034 | Sensor - filling level | |
| 36 | 582 5771 | Dosage, lower part | |
| 37 | 58210028 | D-Dosage | |
| 38 | 58210257 | Seeding mechanism |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
