Каталог запасных частей к технике: Lemken Solitair 12/5800SW. 67511288 Hydraulic assembly
1
2
3
4
5
6
7
8
9
9
9
9
10
11
12
12
12
12
12
13
14
14
15
15
16
16
16
17
17
18
18
18
19
19
19
20
20
22
22
23
23
23
24
25
25
26
26
27
28
29
29
29
29
30
31
31
32
32
33
34
34
35
35
35
36
37
38
39
39
39
40
41
41
42
42
43
43
44
45
45
46
47
48
48
49
51
52
53
54
54
54
55
55
56
57
58
59
59
60
60
61
62
62
62
63
64
65
66
66
67
71
72
73
73
73
73
74
75
76
77
78
79
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 301 1125 | Saucer-head screw | |
| 2 | 301 1802 | Bolt, cup square head | |
| 3 | 301 3006 | Screw | |
| 4 | 301 3066 | Screw | |
| 5 | 301 3073 | Bolt | |
| 6 | 301 3085 | Hexagon bolt | |
| 7 | 30110402 | Hexagon bolt | |
| 8 | 303 0931 | Selflocking nut | |
| 9 | 303 0932 | Selflocking nut | |
| 10 | 303 0934 | Selflocking nut | |
| 11 | 303 1512 | Wing nut | |
| 12 | 305 2051 | Shim | |
| 13 | 305 2242 | Supporting washer | |
| 14 | 305 6124 | Washer | |
| 15 | 305 6958 | Washer | |
| 16 | 305 8571 | Washer | |
| 17 | 305 8580 | Washer | |
| 18 | 305 8694 | Washer | |
| 19 | 305 8867 | Securing ring | |
| 20 | 305 8871 | Securing ring | |
| 21 | 30510072 | Washer | |
| 22 | 313 3003 | Pin with stop | |
| 23 | 313 3028 | Pin with stop | |
| 24 | 31310129 | Pin | |
| 25 | 317 3417 | Expansion bush | |
| 26 | 317 7583 | Bush | |
| 27 | 317 9476 | Bush | |
| 28 | 32110238 | Lever | |
| 29 | 323 6348 | Grease nipple | |
| 30 | 325 1181 | Hose clip | |
| 31 | 325 1521 | Marking | |
| 32 | 325 1523 | Marking | |
| 33 | 325 1526 | Marking | |
| 34 | 325 1528 | Marking | |
| 35 | 325 1533 | Marking | |
| 36 | 32510020 | Marking | |
| 37 | 32510021 | Marking | |
| 38 | 375 2103 | Dust protection flap | |
| 39 | 375 2105 | Dust protection flap | |
| 40 | 375 2121 | Cap | |
| 41 | 375 2123 | Cap | |
| 42 | 375 2166 | Cap, red | |
| 43 | 375 2196 | Vent plug | |
| 44 | 375 2205 | Connection | |
| 45 | 375 2213 | Ball valve | |
| 46 | 375 2719 | SVK-socket | |
| 47 | 375 2732 | SVK-socket | |
| 48 | 375 2736 | SVK-socket | |
| 49 | 375 2737 | SVK-socket | |
| 50 | 375 4028 | Nipple | |
| 51 | 375 4032 | Nipple | |
| 52 | 375 4037 | Nipple | |
| 53 | 375 4399 | Straight bulkhead screw | |
| 54 | 375 4503 | Adjustable angle union | |
| 55 | 375 4507 | Adjustable angle union | |
| 56 | 375 4553 | L-adjustable T-union | |
| 57 | 375 4558 | Adjustable L-union | |
| 58 | 375 4653 | Reduction joint | |
| 59 | 375 9998 | Cover plate | |
| 60 | 37510040 | Plastic male probe | |
| 61 | 37510090 | Nipple | |
| 62 | 37510218 | Clamp | |
| 63 | 37510241 | Dust cap | |
| 64 | 37510325 | Restrictor washer | |
| 65 | 37510390 | Nipple | |
| 66 | 37510409 | Clamp | |
| 67 | 37510410 | Cover plate | |
| 68 | 47310084 | Sensor holder | |
| 69 | 47310088 | Slide guiding | |
| 70 | 47310187 | Slide guiding | |
| 71 | 47510739 | Guard for hoses | |
| 72 | 47511537 | Hydraulic hose | |
| 73 | 47511538 | Hydraulic hose | |
| 74 | 47511541 | Hydraulic hose | |
| 75 | 47511542 | Hydraulic hose | |
| 76 | 47511889 | Hydraulic hose | |
| 77 | 47511913 | Hydraulic hose | |
| 78 | 573 4375 | Proximity switch | |
| 79 | 575 2355 | Ram |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
