Каталог запасных частей к технике: Lemken Solitair 12/1200KD. Contens
1
2
3
4
5
6
7
11
12
13
14
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 59010110 | Label | |
| 1 | 68210389 | Holder | |
| 1 | 68210333 | Basic frame | |
| 1 | 682 9927 | Accessories | |
| 1 | 682 8555 | Link | |
| 1 | 682 8544 | Coulter frame | |
| 1 | 682 8524 | Folding frame | |
| 1 | 682 2537 | Carrier | |
| 1 | 629 7130 | Stand | |
| 2 | 661 8519 | Lift linkage | |
| 2 | 640 8615 | Traction loop | |
| 2 | 640 8614 | Traction loop | |
| 2 | 640 8613 | Traction loop | |
| 2 | 640 8612 | Ball-shaped coupling | |
| 2 | 640 8595 | Traction loop | |
| 2 | 640 8594 | Traction loop | |
| 2 | 640 8593 | Traction loop | |
| 2 | 640 8592 | Ball-shaped coupling | |
| 3 | 675 8343 | HY-assembly lift linkage | |
| 3 | 675 8336 | HY-assembly harrow | |
| 3 | 675 8336 | HY-assembly harrow | |
| 3 | 675 8327 | Braking system, hydraulic | |
| 3 | 675 8319 | HY-assembly track marker fold. | |
| 3 | 675 8345 | Connecting hoses | |
| 3 | 675 8346 | Connecting hoses | |
| 3 | 675 8360 | HY-assembly charging screw | |
| 3 | 675 8441 | Supply hoses | |
| 3 | 675 8445 | Manometric switch | |
| 3 | 67510916 | Hydraulic assembly fan | |
| 3 | 67511102 | HY-assembly lift linkage | |
| 3 | 67511103 | HY-assembly lift linkage | |
| 3 | 675 8318 | HY-assembly track marker | |
| 3 | 675 8317 | Hydraulic assembly balance | |
| 3 | 575 2304 | Ram | |
| 3 | 575 2312 | Plunger-ram | |
| 3 | 575 2314 | Plunger-ram | |
| 3 | 575 2335 | Ram | |
| 3 | 575 2351 | Ram | |
| 3 | 575 2355 | Ram | |
| 3 | 575 2356 | Ram | |
| 3 | 675 8024 | Control valve | |
| 3 | 675 8309 | Mounting parts | |
| 3 | 675 8310 | Hydraulic assembly folding de. | |
| 3 | 675 8314 | HY-assembly lift linkage | |
| 3 | 675 8315 | HY-assembly top link+hose | |
| 3 | 675 8316 | HY-assembly supply hose | |
| 4 | 67310064 | D-GPS receiver | |
| 4 | 67310065 | f. Fahrtrichtung | |
| 4 | 67310066 | Switch box | |
| 4 | 67310067 | Camera monitoring | |
| 4 | 67310068 | Supplementary set | |
| 4 | 67310071 | CCI.Courier | |
| 4 | 67310073 | CCI.Control | |
| 4 | 67310063 | GSM-Box | |
| 4 | 67310022 | Balance | |
| 4 | 673 6218 | Camera monitoring | |
| 4 | 673 6217 | Camera monitoring | |
| 4 | 673 6216 | Camera monitoring | |
| 4 | 673 6211 | Operation terminal | |
| 4 | 673 6210 | Operation terminal | |
| 4 | 673 6207 | Joystickbox | |
| 4 | 673 6155 | Coupling box | |
| 4 | 67310088 | Cable form | |
| 4 | 67310089 | Cable form | |
| 4 | 699 6714 | Operation terminal | |
| 4 | 682 2516 | Pulse wheel | |
| 4 | 682 2514 | Drive wheel | |
| 4 | 67310294 | Holder | |
| 4 | 67310292 | Supplementary set | |
| 4 | 67310290 | Operation terminal | |
| 4 | 67310224 | Electric drive | |
| 4 | 67310223 | Electric drive fertilizer | |
| 4 | 67310221 | Power supply cable | |
| 4 | 67310220 | Cable form | |
| 4 | 67310219 | Equipment | |
| 4 | 67310198 | Operation terminal | |
| 4 | 67310194 | D-GPS receiver | |
| 4 | 67310100 | Section Control | |
| 4 | 67310099 | Parallel driving system | |
| 4 | R18 0156 | Multifunctional handle | |
| 4 | 673 6151 | MDA-job computer | |
| 4 | 57010100 | Lighting unit | |
| 4 | 57310196 | Connecting cable | |
| 4 | 57310195 | Connecting cable | |
| 4 | 573 8034 | Sensor - filling level | |
| 4 | 573 6201 | Adapter | |
| 4 | 573 6179 | Cable | |
| 4 | 573 6172 | Connection cable | |
| 4 | 573 6171 | Connection cable | |
| 4 | 573 6155 | Coupling box | |
| 4 | 573 6133 | Cable form | |
| 4 | 573 6128 | Mounting set, batterie | |
| 4 | 573 4471 | Extension cable | |
| 4 | 573 4431 | Extension cable | |
| 4 | 57010113 | Warning board | |
| 4 | 57010112 | Warning board | |
| 4 | 57010101 | Lighting unit | |
| 4 | 57310197 | Connecting cable | |
| 4 | 57310198 | Connecting cable | |
| 4 | 673 6111 | Cable form | |
| 4 | 673 5060 | Electric assembly f.hy.harrow | |
| 4 | 673 4982 | Holder | |
| 4 | 673 4981 | Holder | |
| 4 | 67010295 | Lighting equipment | |
| 4 | 67010274 | Lighting equipment | |
| 4 | 67010220 | Work lighting | |
| 4 | 67010116 | Wheel chock | |
| 4 | 67010103 | Lighting equipment | |
| 4 | 57310199 | Connecting cable | |
| 4 | 57310241 | Dongle | |
| 4 | 57310278 | Holder | |
| 4 | 57310549 | Operation terminal | |
| 4 | 582 2546 | Extension pulse pick-up wheel | |
| 4 | 670 2090 | Lighting equipment, rear | |
| 4 | 670 2091 | Lighting equipment, front | |
| 5 | 55010049 | Wheel | |
| 5 | 55010048 | Wheel | |
| 5 | 550 8881 | Wheel 10/280/335 | |
| 5 | 550 8880 | Wheel 10/280/335 | |
| 5 | 550 8529 | Running axle | |
| 5 | 550 8527 | Braking axle | |
| 5 | 33110017 | Safety chain | |
| 6 | 682 2729 | Holder, long | |
| 6 | 682 6141 | Pressure roller | |
| 6 | 682 6142 | Pressure roller | |
| 6 | 682 6375 | Scraper | |
| 6 | 682 6401 | Single harrow | |
| 6 | 68210112 | Double disc coulter | |
| 6 | 68210113 | Double disc coulter | |
| 6 | 68210114 | Double disc coulter | |
| 6 | 682 2704 | Levelling harrow | |
| 6 | 657 5017 | Track scraper with holder | |
| 6 | 557 2523 | Holder for track scraper | |
| 6 | 557 4991 | Track scraper | |
| 6 | 582 2704 | Levelling harrow | |
| 6 | 582 2727 | Swinging arm | |
| 6 | 582 5709 | Supplementary set | |
| 6 | 582 6054 | Holder for spring | |
| 6 | 58210024 | Scraper | |
| 6 | 657 5016 | Track scraper | |
| 7 | 682 1339 | Track marker | |
| 7 | 682 1338 | Track marker | |
| 7 | 582 1248 | Axle for track marker | |
| 11 | 582 5617 | Support | |
| 11 | 68210322 | Hopper | |
| 11 | 68210324 | Cover | |
| 11 | 68210479 | Hopper | |
| 11 | 687 1125 | Filling screw | |
| 11 | 68710006 | Filling screw | |
| 12 | 67710011 | Contact breaking cable | |
| 12 | 677 6080 | Compressed-air brake | |
| 12 | 65010031 | Parking brake | |
| 13 | 682 5682 | Fan | |
| 13 | 68210327 | Distributor | |
| 13 | 68210328 | Supply hose | |
| 13 | 68210329 | Supply hose - fertilizer | |
| 13 | 68210330 | Supply hose | |
| 14 | 58210182 | Hose carrier | |
| 14 | 58210184 | Dosage, lower part | |
| 14 | 58210251 | Hose carrier | |
| 14 | 58210252 | Hose carrier | |
| 14 | 68210325 | D-Dosage | |
| 14 | 58210181 | Hose carrier | |
| 14 | 58210180 | Hose carrier | |
| 14 | 58210178 | Dosage, lower part | |
| 14 | 58210170 | Seeding mechanism fertilizer | |
| 14 | 58210169 | Seeding mechanism | |
| 14 | 582 5836 | Agitator finger | |
| 14 | 582 5781 | Dosage, top part | |
| 14 | 68210335 | D-Dosage |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
