Каталог запасных частей к технике: Lemken Solitair 12/1200KD. 6758343 HY-assembly lift linkage
1
2
3
4
5
7
8
9
10
11
12
17
18
19
20
21
22
23
24
25
28
28
29
29
30
31
32
33
34
35
36
37
38
39
40
41
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 301 0309 | Flatheaded bolt | |
| 2 | 301 3347 | Screw | |
| 3 | 303 0931 | Selflocking nut | |
| 4 | 303 0934 | Selflocking nut | |
| 5 | 305 2051 | Shim | |
| 7 | 305 8867 | Securing ring | |
| 8 | 309 7000 | Expansion bush | |
| 9 | 313 3011 | Pin | |
| 10 | 313 3023 | Pin with stop | |
| 11 | 317 3417 | Expansion bush | |
| 12 | 323 6348 | Grease nipple | |
| 17 | 375 2121 | Cap | |
| 18 | 375 2718 | SVK-socket | |
| 19 | 375 4038 | Nipple | |
| 20 | 375 4039 | Nipple | |
| 21 | 375 4311 | Union, swivel | |
| 22 | 375 4490 | T-adjustable T-union | |
| 23 | 375 4500 | Adjustable angle union | |
| 24 | 375 4550 | L-adjustable T-union | |
| 25 | 375 4711 | Stud | |
| 28 | 475 3060 | High-pressure hose | |
| 29 | 475 3064 | High-pressure hose | |
| 30 | 475 3065 | High-pressure hose | |
| 31 | 475 3067 | High-pressure hose | |
| 32 | 475 4375 | Hose carrier | |
| 33 | 57510336 | Tube | |
| 34 | 575 2051 | Pressure limiting valve | |
| 35 | 575 2165 | Nonreturn valve | |
| 36 | 575 2356 | Ram | |
| 37 | 325 1603 | Marking | |
| 38 | 325 1610 | Marking | |
| 39 | 375 2606 | Insert | |
| 40 | 375 2607 | Handle | |
| 41 | 57510684 | Nonreturn valve |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
