Каталог запасных частей к технике: Lemken Primus 10 (Часть 1). Contents
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
5
6
6
6
6
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
8
8
8
8
8
8
9
9
9
9
9
9
9
9
9
9
9
9
9
9
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
11
11
11
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
12
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 59110217 | Box | |
| 1 | 69110306 | Angle | |
| 1 | 69110286 | Cover | |
| 1 | 69110243 | Basic frame | |
| 1 | 69110242 | Basic frame | |
| 1 | 69110241 | Platform | |
| 1 | 69110240 | Guardrail | |
| 1 | 69110233 | Box | |
| 1 | 69110140 | Hose carrier | |
| 2 | 67810252 | Clean water tank | |
| 2 | 67810264 | Water canister | |
| 2 | 69110226 | Full-standing view indirectly | |
| 2 | 69110227 | Full-standing view indirectly | |
| 2 | 69110228 | Full-standing view indirectly | |
| 2 | 67810246 | Main tank | |
| 2 | 67810245 | Main tank | |
| 2 | 67810244 | Main tank | |
| 2 | 57810471 | Main tank | |
| 2 | 57810470 | Main tank | |
| 2 | 57810469 | Main tank | |
| 2 | 57810248 | Water canister | |
| 2 | 47810242 | Hopper venting | |
| 3 | 69110275 | Linkage | |
| 3 | 69110276 | Linkage | |
| 3 | 69110277 | Linkage | |
| 3 | 69110278 | Linkage | |
| 3 | 69110279 | Linkage | |
| 3 | 69110274 | Linkage | |
| 3 | 69110273 | Linkage | |
| 3 | 69110272 | Linkage | |
| 3 | 69110271 | Linkage | |
| 3 | 69110270 | Linkage | |
| 3 | 69110269 | Linkage | |
| 3 | 69110268 | Linkage | |
| 3 | 69110280 | Linkage | |
| 3 | 69110281 | Linkage | |
| 3 | R74 1625 | Guiding | |
| 3 | R73 9957 | Mountain | |
| 3 | R73 8531 | Slide | |
| 3 | R73 8521 | Slide | |
| 3 | R70 3705 | Guiding | |
| 3 | R70 1751 | Guiding | |
| 3 | R70 1741 | Guiding | |
| 3 | 69110308 | Shock absorber set | |
| 3 | 69110307 | Shock absorber set | |
| 3 | 69110293 | Energy chain | |
| 3 | 69110290 | Slide | |
| 3 | R74 1635 | Guiding | |
| 3 | 69110267 | Linkage | |
| 3 | 33110086 | Energy chain | |
| 3 | 69110153 | Shock absorber | |
| 3 | 59110234 | Shock absorber set | |
| 3 | 59110233 | Shock absorber set | |
| 3 | 59110232 | Shock absorber set | |
| 3 | 59110216 | Guiding | |
| 3 | 59110209 | Arm | |
| 3 | 59110208 | Arm | |
| 3 | 59110207 | Arm | |
| 3 | 59110206 | Arm | |
| 3 | 59110205 | Arm | |
| 3 | 59110204 | Arm | |
| 3 | 69110248 | Center section | |
| 3 | 69110249 | Center section | |
| 3 | 69110266 | Linkage | |
| 3 | 69110265 | Linkage | |
| 3 | 69110260 | Spacer | |
| 3 | 69110259 | Support | |
| 3 | 69110258 | Support | |
| 3 | 69110256 | Slide guiding | |
| 3 | 69110255 | Center section | |
| 3 | 69110254 | Center section | |
| 3 | 69110253 | Center section | |
| 3 | 69110252 | Center section | |
| 3 | 69110251 | Center section | |
| 3 | 69110250 | Center section | |
| 4 | 67810261 | Piston diaphragm pump | |
| 4 | 67810258 | Suction fitting | |
| 4 | 67810255 | Suction fitting | |
| 4 | 67810236 | Pressure fitting | |
| 4 | 67810233 | Pressure fitting | |
| 4 | 67810232 | Connection | |
| 4 | 67810262 | Piston diaphragm pump | |
| 4 | 69110261 | Cover | |
| 4 | 69110282 | Cover | |
| 4 | F61 0137 | Ball valve | |
| 4 | R52 0016 | Ball valve | |
| 4 | R52 0017 | Ball valve | |
| 4 | R52 0018 | Ball valve | |
| 4 | R52 0022 | Ball valve | |
| 4 | R52 0443 | Press filter | |
| 4 | 67810231 | External cleaning | |
| 4 | 67810230 | Blind plug | |
| 4 | 57810462 | Adapter | |
| 4 | 57810002 | Suction filter | |
| 4 | 57810008 | Nonreturn valve | |
| 4 | 57810014 | Piston diaphragm pump | |
| 4 | 57810032 | Flowmeter | |
| 4 | 57810033 | Flowmeter | |
| 4 | 57810095 | Ball valve | |
| 4 | 57810101 | Control valve unit | |
| 4 | 57810105 | Pressure accumulator | |
| 4 | 57810197 | Pressure limiting valve | |
| 4 | 57810461 | Adapter | |
| 4 | 57810460 | Adapter | |
| 4 | 57810459 | Adapter | |
| 4 | 57810300 | Control valve unit | |
| 4 | 57810201 | Piston diaphragm pump | |
| 4 | 57810200 | Nonreturn valve | |
| 5 | R74 0001 | Suction hose | |
| 5 | R73 9999 | Suction hose | |
| 5 | R73 9998 | Suction hose | |
| 5 | R73 9991 | Suction hose | |
| 5 | R73 9951 | External cleaning set | |
| 5 | R70 3301 | Induction valves | |
| 5 | R00 0656 | Cleaning pistol | |
| 5 | F61 4562 | Measuring jug | |
| 5 | F61 4245 | Control center | |
| 5 | F61 0613 | Drain cock | |
| 5 | 69110206 | Chemical inductor | |
| 6 | R00 1955 | Wide-angle PTO drive shaft | |
| 6 | R00 1513 | Cardan shaft | |
| 6 | R00 1129 | Cardan shaft | |
| 6 | R00 1127 | Cardan shaft | |
| 7 | 67310229 | Level control | |
| 7 | 67310230 | Level control | |
| 7 | 67310231 | Auxiliary equipment | |
| 7 | 67310232 | Auxiliary equipment | |
| 7 | 67310270 | Electronic installation | |
| 7 | 67310272 | Electronic installation | |
| 7 | 67310285 | Electronic installation | |
| 7 | 69110303 | Sensor holder | |
| 7 | 69110304 | Sensor holder | |
| 7 | 69110305 | Sensor holder | |
| 7 | F40 2175 | Cable | |
| 7 | R18 0156 | Multifunctional handle | |
| 7 | 67310225 | Tractor mounting set | |
| 7 | 67310194 | D-GPS receiver | |
| 7 | 67310175 | Sensory mechanism | |
| 7 | 57310199 | Connecting cable | |
| 7 | 57310532 | Sensory mechanism | |
| 7 | 59110122 | Sensor holder | |
| 7 | 59110123 | Sensor holder | |
| 7 | 673 4981 | Holder | |
| 7 | 673 4982 | Holder | |
| 7 | 673 6218 | Camera monitoring | |
| 7 | 67310064 | D-GPS receiver | |
| 7 | 67310067 | Camera monitoring | |
| 7 | 67310073 | CCI.Control | |
| 7 | 67310099 | Parallel driving system | |
| 7 | 67310100 | Section Control | |
| 8 | 67511059 | HY-assembly basic implement | |
| 8 | 67511058 | HY-assembly lifting | |
| 8 | 67511055 | HY-assembly lifting | |
| 8 | 57511176 | Hydraulic ram | |
| 8 | 57510747 | Hydraulic ram | |
| 8 | 57510228 | Hydraulic ram | |
| 9 | 57010124 | Lighting unit | |
| 9 | 57010125 | Lighting unit | |
| 9 | 57010126 | Lighting unit | |
| 9 | 57010127 | Lighting unit | |
| 9 | 67010226 | Lighting equipment | |
| 9 | 67310286 | Lighting equipment | |
| 9 | 57010099 | Lighting unit | |
| 9 | 57010098 | Lighting unit | |
| 9 | 37310032 | Tail light | |
| 9 | 37310126 | Rear light | |
| 9 | 37310127 | Rear light | |
| 9 | 37310130 | Position light | |
| 9 | 57010096 | Lighting unit | |
| 9 | 57010097 | Lighting unit | |
| 10 | 67810313 | Liquid cycle | |
| 10 | 67810314 | Liquid cycle | |
| 10 | 67810315 | Liquid cycle | |
| 10 | 67810316 | Liquid cycle | |
| 10 | 67810317 | Liquid cycle | |
| 10 | 67810318 | Liquid cycle | |
| 10 | 67810319 | Liquid cycle | |
| 10 | 67810320 | Liquid cycle | |
| 10 | 67810321 | Liquid cycle | |
| 10 | 67810312 | Liquid cycle | |
| 10 | 67810311 | Liquid cycle | |
| 10 | 67810310 | Liquid cycle | |
| 10 | 67810301 | Liquid cycle | |
| 10 | 67810302 | Liquid cycle | |
| 10 | 67810303 | Liquid cycle | |
| 10 | 67810304 | Liquid cycle | |
| 10 | 67810305 | Liquid cycle | |
| 10 | 67810306 | Liquid cycle | |
| 10 | 67810307 | Liquid cycle | |
| 10 | 67810308 | Liquid cycle | |
| 10 | 67810309 | Liquid cycle | |
| 10 | 67810322 | Liquid cycle | |
| 10 | 67810323 | Liquid cycle | |
| 10 | 67810324 | Liquid cycle | |
| 10 | 67810336 | Liquid cycle | |
| 10 | 67810337 | Liquid cycle | |
| 10 | 67810338 | Liquid cycle | |
| 10 | 67810339 | Liquid cycle | |
| 10 | 67810340 | Liquid cycle | |
| 10 | 67810341 | Liquid cycle | |
| 10 | 67810342 | Liquid cycle | |
| 10 | 67810343 | Liquid cycle | |
| 10 | R00 1363 | Control valve unit | |
| 10 | 67810335 | Liquid cycle | |
| 10 | 67810334 | Liquid cycle | |
| 10 | 67810325 | Liquid cycle | |
| 10 | 67810326 | Liquid cycle | |
| 10 | 67810327 | Liquid cycle | |
| 10 | 67810328 | Liquid cycle | |
| 10 | 67810329 | Liquid cycle | |
| 10 | 67810330 | Liquid cycle | |
| 10 | 67810331 | Liquid cycle | |
| 10 | 67810332 | Liquid cycle | |
| 10 | 67810333 | Liquid cycle | |
| 10 | R00 1589 | Valve | |
| 10 | 67810300 | Liquid cycle | |
| 10 | 57810280 | Plug | |
| 10 | 67810241 | End nozzle | |
| 10 | 67810242 | Electr. boundary nozzle | |
| 10 | 67810243 | Electr. boundary nozzle | |
| 10 | 67810267 | Hose-assembly | |
| 10 | 67810268 | Hose-assembly | |
| 10 | 67810272 | Liquid cycle | |
| 10 | 67810273 | Liquid cycle | |
| 10 | 67810274 | Liquid cycle | |
| 10 | 67810275 | Liquid cycle | |
| 10 | 67810240 | End nozzle | |
| 10 | 57810481 | T-piece | |
| 10 | 57810295 | Nozzle holder | |
| 10 | 57810301 | Nozzle holder | |
| 10 | 57810302 | Nozzle holder | |
| 10 | 57810304 | Control valve unit | |
| 10 | 57810468 | Valve | |
| 10 | 57810477 | Distributor | |
| 10 | 57810478 | Liquid cycle | |
| 10 | 57810479 | Liquid cycle | |
| 10 | 57810480 | T-piece | |
| 10 | 67810276 | Liquid cycle | |
| 10 | 67810277 | Liquid cycle | |
| 10 | 67810278 | Liquid cycle | |
| 10 | 67810291 | Liquid cycle | |
| 10 | 67810292 | Liquid cycle | |
| 10 | 67810293 | Liquid cycle | |
| 10 | 67810294 | Liquid cycle | |
| 10 | 67810295 | Liquid cycle | |
| 10 | 67810296 | Liquid cycle | |
| 10 | 67810297 | Liquid cycle | |
| 10 | 67810298 | Liquid cycle | |
| 10 | 67810299 | Liquid cycle | |
| 10 | 67810290 | Liquid cycle | |
| 10 | 67810289 | Liquid cycle | |
| 10 | 67810288 | Liquid cycle | |
| 10 | 67810279 | Liquid cycle | |
| 10 | 67810280 | Liquid cycle | |
| 10 | 67810281 | Liquid cycle | |
| 10 | 67810282 | Liquid cycle | |
| 10 | 67810283 | Liquid cycle | |
| 10 | 67810284 | Liquid cycle | |
| 10 | 67810285 | Liquid cycle | |
| 10 | 67810286 | Liquid cycle | |
| 10 | 67810287 | Liquid cycle | |
| 11 | R70 5985 | Ball-shaped coupling | |
| 11 | R70 5970 | Traction loop | |
| 11 | R70 5965 | Traction loop | |
| 11 | R70 5960 | Ball-shaped coupling | |
| 11 | R70 5955 | Traction loop | |
| 11 | R70 5950 | Traction loop | |
| 11 | 69110302 | Zylinderaufnahme | |
| 11 | 69110301 | Zwischenstuck Zylinderaufnahme | |
| 11 | 69110300 | Zwischenstuck Zylinderaufnahme | |
| 11 | 69110219 | Drawbar extension | |
| 11 | 69110211 | Drawbar extension | |
| 12 | 69110264 | Stand | |
| 12 | 69110225 | Drawbar suspension | |
| 12 | 69110224 | Drawbar | |
| 12 | 69110217 | Drawbar | |
| 12 | 59110202 | Halter Gelenkwelle | |
| 12 | 59110201 | Holder | |
| 12 | 59110198 | Pin | |
| 12 | 31310012 | Socket pin | |
| 13 | R36 0230 | Braking axle | |
| 13 | R36 0240 | Braking axle | |
| 13 | R36 0250 | Braking axle | |
| 13 | R36 0260 | Braking axle | |
| 13 | R36 0270 | Braking axle | |
| 13 | R36 0320 | Braking axle | |
| 13 | R36 0330 | Braking axle | |
| 13 | R36 0340 | Braking axle | |
| 13 | R36 0220 | Braking axle | |
| 13 | R36 0210 | Braking axle | |
| 13 | R36 0200 | Braking axle | |
| 13 | R36 0000 | Running axle | |
| 13 | R36 0010 | Running axle | |
| 13 | R36 0020 | Running axle | |
| 13 | R36 0030 | Running axle | |
| 13 | R36 0040 | Running axle | |
| 13 | R36 0050 | Running axle | |
| 13 | R36 0060 | Running axle | |
| 13 | R36 0070 | Running axle | |
| 13 | R36 0350 | Braking axle | |
| 13 | R36 0360 | Braking axle | |
| 13 | R36 0370 | Braking axle | |
| 13 | R36 8510 | Running axle end | |
| 13 | R36 8540 | Breaking axle stub | |
| 13 | R36 8550 | Breaking axle stub | |
| 13 | R36 8560 | Breaking axle stub | |
| 13 | R36 8570 | Breaking axle stub | |
| 13 | R96 1801 | Running axle | |
| 13 | R96 1802 | Bremsachse starr | |
| 13 | R96 1803 | Bremsachse starr | |
| 13 | R36 8500 | Running axle end | |
| 13 | R36 1736 | Braking axle | |
| 13 | R36 0540 | Braking axle | |
| 13 | R36 0545 | Braking axle | |
| 13 | R36 0550 | Braking axle | |
| 13 | R36 0555 | Braking axle | |
| 13 | R36 0610 | Axle | |
| 13 | R36 1725 | Axle | |
| 13 | R36 1726 | Braking axle | |
| 13 | R36 1735 | Axle | |
| 13 | R96 1805 | Braking axle | |
| 13 | 55010331 | Holder for mud guard | |
| 13 | 67710099 | Compressed-air brake | |
| 13 | 67710100 | Compressed-air brake | |
| 13 | 67710101 | Compressed-air brake | |
| 13 | 67710102 | Compressed-air brake | |
| 13 | 67710109 | Compressed-air brake | |
| 13 | 699 6810 | Wheelset | |
| 13 | 699 6811 | Wheel | |
| 13 | 699 6812 | Wheel | |
| 13 | 67010179 | Wheel chock | |
| 13 | 65010114 | Mud guard | |
| 13 | 65010106 | Mud guard | |
| 13 | 65010107 | Mud guard | |
| 13 | 65010108 | Mud guard | |
| 13 | 65010109 | Mud guard | |
| 13 | 65010110 | Mud guard | |
| 13 | 65010111 | Mud guard | |
| 13 | 65010112 | Mud guard | |
| 13 | 65010113 | Mud guard | |
| 13 | 699 6813 | Wheel | |
| 13 | 699 6814 | Wheel | |
| 13 | 699 6815 | Wheel | |
| 13 | 699 6826 | Wheel | |
| 13 | 699 6827 | Wheel | |
| 13 | 699 6828 | Wheel | |
| 13 | 699 6829 | Wheel | |
| 13 | 699 6830 | Wheel | |
| 13 | 699 6831 | Wheel | |
| 13 | 699 6832 | Wheel | |
| 13 | 699 6833 | Wheel | |
| 13 | 699 6825 | Wheel | |
| 13 | 699 6824 | Wheel | |
| 13 | 699 6816 | Wheel | |
| 13 | 699 6817 | Wheel | |
| 13 | 699 6818 | Wheel | |
| 13 | 699 6819 | Wheel | |
| 13 | 699 6820 | Wheel | |
| 13 | 699 6821 | Wheel | |
| 13 | 699 6822 | Wheel | |
| 13 | 699 6823 | Wheel | |
| 13 | R00 0088 | Chassis, pneum., spring-loaded |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
