Каталог запасных частей к технике: Lemken Juwel 8M. 54910008 Wheel stalk
3
4
5
7
8
8
9
10
12
13
14
16
16
17
17
19
22
23
24
25
26
28
29
31
32
33
33
39
41
45
47
49
54
54
56
64
74
75
76
79
80
82
83
84
86
86
87
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 3 | 301 4607 | Bolt | |
| 4 | 301 4700 | Bolt | |
| 5 | 301 3920 | Bolt | |
| 7 | 303 0142 | Castle nut | |
| 8 | 303 0935 | Selflocking nut | |
| 9 | 303 0936 | Selflocking nut | |
| 10 | 303 0937 | Selflocking nut | |
| 12 | 301 5390 | Bolt | |
| 13 | 305 2095 | Shim | |
| 14 | 305 2250 | Supporting washer | |
| 16 | 305 6141 | Washer | |
| 17 | 305 6254 | Washer | |
| 19 | 305 6425 | Washer | |
| 22 | 305 8875 | Securing ring | |
| 23 | 311 7648 | Peg | |
| 24 | 311 9565 | Securing pin | |
| 25 | 313 1816 | Pin with grip | |
| 26 | 31310039 | Axle | |
| 28 | 317 3036 | Expansion bush | |
| 29 | 317 3037 | Expansion bush | |
| 31 | 317 3039 | Expansion bush | |
| 32 | 317 3413 | Expansion bush | |
| 33 | 31710183 | Expansion bush | |
| 38 | 323 0530 | Thrust washer | |
| 39 | 323 6348 | Grease nipple | |
| 41 | 323 8054 | Cap | |
| 45 | 449 3001 | Bracket | |
| 47 | 44910020 | Wheel stalk | |
| 49 | 549 8904 | Flange-type bearing | |
| 54 | 305 6012 | Washer | |
| 56 | 30510175 | Washer | |
| 64 | 449 1644 | Scraper | |
| 74 | 375 1295 | O-ring | |
| 75 | 44910005 | Bushing | |
| 76 | 44910006 | Axle | |
| 79 | 44910009 | Swinging arm | |
| 80 | 303 6416 | Wheel nut | |
| 82 | 301 3000 | Screw | |
| 83 | 305 8571 | Washer | |
| 84 | 301 3976 | Hexagon bolt | |
| 86 | 31710304 | Expansion bush | |
| 87 | 31710305 | Expansion bush |
