Каталог запасных частей к технике: Lemken EurOpal 8. EurOpal 8
1
1
2
2
2
2
3
4
4
4
4
4
5
5
5
5
5
5
6
6
6
6
6
6
6
6
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
8
8
9
9
9
9
9
9
9
10
10
11
11
11
11
11
11
11
11
11
11
11
11
12
12
12
13
13
13
13
13
13
15
15
15
16
16
16
16
16
16
16
16
16
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 313 7911 | Top link pin with chain | |
| 1 | 313 7921 | Top link pin with chain | |
| 2 | 321 9121 | Tool set | |
| 2 | 633 7510 | Turnover mechanism | |
| 2 | 633 7511 | Turnover mechanism | |
| 2 | 633 7515 | Turnover mechanism | |
| 3 | 633 7431 | Locking device | |
| 4 | 634 3164 | Adjustment centre | |
| 4 | 634 3163 | Adjustment centre | |
| 4 | 634 3162 | Adjustment centre | |
| 4 | 634 3161 | Adjustment centre | |
| 4 | 634 3160 | Adjustment centre | |
| 5 | 629 2512 | Stand | |
| 5 | 629 2486 | Stand | |
| 5 | 629 2485 | Stand | |
| 5 | 629 2475 | Stand | |
| 5 | 629 2474 | Stand | |
| 5 | 629 2470 | Stand | |
| 6 | 661 1406 | Lower link connection | |
| 6 | 661 1405 | Lower link connection | |
| 6 | 661 1402 | Lower link connection | |
| 6 | 661 1401 | Lower link connection | |
| 6 | 661 1388 | Lower link connection | |
| 6 | 661 1387 | Lower link connection | |
| 6 | 661 1386 | Lower link connection | |
| 6 | 661 1385 | Lower link connection | |
| 7 | 602 8553 | Basic frame | |
| 7 | 602 8554 | Basic frame | |
| 7 | 602 8555 | Basic frame | |
| 7 | 602 8556 | Basic frame | |
| 7 | 602 8557 | Basic frame | |
| 7 | 602 8558 | Basic frame | |
| 7 | 602 8552 | Basic frame | |
| 7 | 602 8277 | Basic frame | |
| 7 | 602 8276 | Basic frame | |
| 7 | 602 8275 | Basic frame | |
| 7 | 602 8274 | Basic frame | |
| 7 | 602 8272 | Basic frame | |
| 7 | 602 8271 | Basic frame | |
| 7 | 602 8270 | Basic frame | |
| 7 | 602 8269 | Basic frame | |
| 8 | 602 8278 | Frame extension | |
| 8 | 602 8273 | Frame extension | |
| 9 | 663 8651 | Skim stalk | |
| 9 | 663 8750 | Skim stalk | |
| 9 | 663 8752 | Skim stalk | |
| 9 | 663 8754 | Skim stalk | |
| 9 | 663 8755 | Skim stalk | |
| 9 | 663 8759 | Skim stalk | |
| 9 | 663 8764 | Skim stalk | |
| 10 | 699 0955 | Leg | |
| 10 | 699 0901 | Bolts for leg | |
| 11 | 649 1349 | Uni-wheel | |
| 11 | 649 1336 | Uni-wheel | |
| 11 | 649 1335 | Uni-wheel | |
| 11 | 648 4160 | Depth wheel | |
| 11 | 549 8893 | Bearing | |
| 11 | 549 8849 | Wheel 5/94/140 D14 | |
| 11 | 549 1337 | Uni-wheel | |
| 11 | 549 1335 | Uni-wheel | |
| 11 | 548 4167 | Depth wheel | |
| 11 | 548 4158 | Depth wheel | |
| 11 | 548 2607 | Wheel stalk with bearing | |
| 11 | 548 2606 | Wheel stalk with bearing | |
| 12 | 670 2012 | Lighting equipment with boards | |
| 12 | 670 1200 | Carrier for light | |
| 12 | 670 1151 | Carrier for light | |
| 13 | 657 7855 | Disc coulter | |
| 13 | 657 7854 | Disc coulter | |
| 13 | 657 7853 | Disc coulter | |
| 13 | 657 7843 | Disc coulter | |
| 13 | 657 7842 | Disc coulter | |
| 13 | 657 7841 | Disc coulter | |
| 15 | 622 2666 | Bracket | |
| 15 | 622 2661 | Attachment arm | |
| 15 | 622 2660 | Attachment arm | |
| 16 | 675 3650 | HY-turnover device | |
| 16 | 675 3600 | HY-width adjuster Memory-VUP | |
| 16 | 675 3599 | HY-width adjuster Memory-VUP | |
| 16 | 675 3598 | HY-width adjuster Memory-VUP | |
| 16 | 675 3589 | HY-width adjuster Memory | |
| 16 | 675 3562 | HY-front furrow adjustment | |
| 16 | 675 1346 | HY-assembly attachment arm | |
| 16 | 675 1340 | HY-assembly attachment arm | |
| 16 | 675 3651 | HY-turnover+swing-in device |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
