Каталог запасных частей к технике: Lemken EurOpal 5. EurOpal 5
1
1
2
2
2
3
4
4
4
4
5
5
6
6
6
6
6
6
6
6
7
7
7
7
8
8
9
9
9
9
10
10
11
11
11
11
11
11
11
11
11
11
11
12
12
12
13
13
13
13
15
15
16
16
16
16
16
16
16
16
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 313 7911 | Top link pin with chain | |
| 1 | 313 7921 | Top link pin with chain | |
| 2 | 321 9108 | Tool set | |
| 2 | 633 7500 | Turnover mechanism | |
| 2 | 633 7501 | Turnover mechanism | |
| 3 | 633 7428 | Locking device | |
| 4 | 634 3142 | Adjustment centre | |
| 4 | 634 3141 | Adjustment centre | |
| 4 | 302 8720 | Turnbuckle | |
| 4 | 302 8714 | Turnbuckle | |
| 5 | 629 2487 | Stand | |
| 5 | 629 2488 | Stand | |
| 6 | 661 1406 | Lower link connection | |
| 6 | 661 1405 | Lower link connection | |
| 6 | 661 1402 | Lower link connection | |
| 6 | 661 1401 | Lower link connection | |
| 6 | 661 1388 | Lower link connection | |
| 6 | 661 1387 | Lower link connection | |
| 6 | 661 1386 | Lower link connection | |
| 6 | 661 1385 | Lower link connection | |
| 7 | 602 8236 | Basic frame | |
| 7 | 602 8235 | Basic frame | |
| 7 | 602 8234 | Basic frame | |
| 7 | 602 8233 | Basic frame | |
| 8 | 602 8246 | Frame extension | |
| 8 | 602 8247 | Frame extension | |
| 9 | 663 8750 | Skim stalk | |
| 9 | 663 8752 | Skim stalk | |
| 9 | 663 8781 | Skim stalk | |
| 9 | 663 8783 | Skim stalk | |
| 10 | 699 0959 | Leg | |
| 10 | 699 0901 | Bolts for leg | |
| 11 | 649 1339 | Uni-wheel | |
| 11 | 649 1338 | Uni-wheel | |
| 11 | 648 4156 | Depth wheel | |
| 11 | 648 4155 | Depth wheel | |
| 11 | 550 8863 | Wheel 6/161/205 D18 | |
| 11 | 549 8859 | Wheel 5/94/140 D14 | |
| 11 | 549 8849 | Wheel 5/94/140 D14 | |
| 11 | 549 1339 | Uni-wheel | |
| 11 | 549 1338 | Uni-wheel | |
| 11 | 548 4165 | Depth wheel | |
| 11 | 548 4155 | Depth wheel | |
| 12 | 670 2012 | Lighting equipment with boards | |
| 12 | 670 1200 | Carrier for light | |
| 12 | 670 1151 | Carrier for light | |
| 13 | 657 7849 | Disc coulter | |
| 13 | 657 7848 | Disc coulter | |
| 13 | 657 7840 | Disc coulter | |
| 13 | 657 7839 | Disc coulter | |
| 14 | 642 6809 | Headland attachment disc | |
| 15 | 622 2660 | Attachment arm | |
| 15 | 622 2661 | Attachment arm | |
| 16 | 675 3655 | HY-turnover device | |
| 16 | 675 3639 | HY-turnover device | |
| 16 | 675 3635 | HY-turnover device | |
| 16 | 675 3634 | HY-turnover device | |
| 16 | 675 3550 | HY-front furrow adjustment | |
| 16 | 675 3276 | HY-frame swing-in device | |
| 16 | 675 1340 | HY-assembly attachment arm | |
| 16 | 675 3656 | HY-turnover device |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
