Каталог запасных частей к технике: Lemken Azurit 9. 30210077 Contents
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
3
3
3
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
7
7
7
7
7
7
7
7
8
8
8
8
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
12
12
12
12
12
12
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 30210077 | Turnbuckle | |
| 1 | 68310051 | Cover | |
| 1 | 68310058 | Coulter frame | |
| 1 | 68310059 | Coulter frame | |
| 1 | 68310062 | Basic frame | |
| 1 | 68310082 | Coulter frame | |
| 1 | 68310083 | Coulter frame | |
| 1 | 68310084 | Coulter frame | |
| 1 | 68310085 | Coulter frame | |
| 1 | 68310094 | Holder | |
| 1 | 68310095 | Holder | |
| 1 | 68310115 | Cover | |
| 1 | 68310116 | Accessories | |
| 1 | 68310047 | Coulter frame | |
| 1 | 68310046 | Coulter frame | |
| 1 | 321 9845 | Spanner | |
| 1 | 59010101 | Label set | |
| 1 | 59010103 | Label set | |
| 1 | 68310011 | Center section | |
| 1 | 68310020 | Lateral section | |
| 1 | 68310021 | Lateral section | |
| 1 | 68310026 | Coulter frame | |
| 1 | 68310041 | Coulter frame | |
| 1 | 68310040 | Coulter frame | |
| 1 | 68310039 | Lateral section | |
| 1 | 68310038 | Lateral section | |
| 1 | 68310027 | Coulter frame | |
| 2 | 68310053 | Emptying unit for hopper | |
| 2 | 68310050 | Hopper | |
| 2 | 68310045 | Pre-dosage | |
| 2 | 68310044 | Pre-dosage | |
| 2 | 68310035 | Pre-dosage | |
| 2 | 68310034 | Pre-dosage | |
| 2 | 68310033 | Pre-dosage | |
| 2 | 68310032 | Pre-dosage lower part | |
| 3 | 68310066 | Step | |
| 3 | 68310065 | Step | |
| 3 | 68310028 | Step | |
| 4 | 68310093 | Cover | |
| 4 | 68310049 | Air filter | |
| 4 | 68310042 | Cover | |
| 4 | 68310031 | Fan | |
| 4 | 58310010 | Fan | |
| 4 | 58210111 | Fan | |
| 5 | 68310014 | Disc carrier | |
| 5 | 68310015 | Disc carrier | |
| 5 | 68310067 | Levelling roller | |
| 5 | 68310068 | Double disc coulter | |
| 5 | 68310069 | Roughing star | |
| 5 | 68310092 | Scraper | |
| 5 | 68310101 | Seed disc | |
| 5 | 68310102 | Seed disc | |
| 5 | 68310106 | Seed disc | |
| 5 | 68310107 | Seed disc | |
| 5 | 68310114 | Thinning out device | |
| 5 | 68310123 | Depth guiding | |
| 5 | 69910420 | Coulter | |
| 5 | 68310009 | Depth guiding | |
| 5 | 68310004 | Catching roller unit | |
| 5 | 68310003 | Trapeze packer roller | |
| 5 | 54710005 | Catching roller | |
| 5 | 54710008 | Depth guiding roller | |
| 5 | 54710009 | Roller | |
| 5 | 54710011 | Catching roller | |
| 5 | 58210083 | Link | |
| 5 | 58210084 | Bracket | |
| 5 | 58310005 | Parallelogram | |
| 5 | 58310006 | Parallelogram | |
| 5 | 58310015 | Parallelogram | |
| 5 | 58310022 | Cover box | |
| 5 | 58310023 | Cover box | |
| 5 | 58310030 | Depth guiding roller | |
| 5 | 68310002 | Parallelogram | |
| 6 | 68310087 | Distributor | |
| 6 | 68310090 | Hose guiding | |
| 6 | 68310118 | Distributor | |
| 6 | 68310119 | Distributor | |
| 6 | 68310120 | Distributor | |
| 6 | 68310121 | Distributor | |
| 6 | 68310122 | Distributor | |
| 6 | 68310086 | Distributor | |
| 6 | 68310079 | Hose guiding | |
| 6 | 68310052 | Hose guiding | |
| 6 | 68310054 | Distributor | |
| 6 | 68310055 | Distributor | |
| 6 | 68310056 | Distributor | |
| 6 | 68310057 | Distributor | |
| 6 | 68310064 | Distributor | |
| 6 | 68310078 | Hose guiding | |
| 7 | 68310043 | Lower link connection | |
| 7 | 68310029 | Lower link connection | |
| 7 | 66110011 | Lower link connection | |
| 7 | 661 1368 | Lower link connection | |
| 7 | 661 1367 | Lower link connection | |
| 7 | 57511362 | Repair kit | |
| 7 | 31310158 | Top link pin | |
| 7 | 31310070 | Top link pin | |
| 8 | 657 4998 | Track scraper with holder | |
| 8 | 657 4990 | Track scraper with holder | |
| 8 | 557 4995 | Track scraper | |
| 8 | 557 2520 | Holder for track scraper | |
| 9 | 67510807 | HY-assembly curr.regulat.valve | |
| 9 | 67510808 | Hydraulic assembly | |
| 9 | 67510809 | HY assembly seeding bar | |
| 9 | 67510811 | Hy-assembly seeding bar | |
| 9 | 67510812 | Hy-assembly seeding bar | |
| 9 | 67510813 | HY-assembly track marker | |
| 9 | 67510856 | Hy-assembly seeding bar | |
| 9 | 67510857 | Hy-assembly seeding bar | |
| 9 | 67510989 | Hy-assembly seeding bar | |
| 9 | 67510805 | HY-assembly track marker | |
| 9 | 67510804 | Hydraulic assembly fan | |
| 9 | 575 2533 | Ram | |
| 9 | 575 2553 | Hydraulic ram | |
| 9 | 575 2576 | Hydraulic ram | |
| 9 | 57510820 | Hydraulic motor | |
| 9 | 57510984 | Hydraulic ram | |
| 9 | 57510988 | Hydraulic ram | |
| 9 | 57510991 | Valve combination | |
| 9 | 67510802 | HY-assembly track marker | |
| 9 | 67510803 | HY-assembly basic equipment | |
| 10 | 57010132 | Lighting unit | |
| 10 | 57010103 | Lighting unit | |
| 10 | 57010102 | Lighting unit | |
| 10 | 57010095 | Protective tilt | |
| 10 | 57010094 | Protective tilt | |
| 10 | 57010093 | Protective tilt | |
| 10 | 57010092 | Protective tilt | |
| 10 | 57010133 | Lighting unit | |
| 10 | 67010137 | Cable | |
| 10 | 67010138 | Cable | |
| 10 | 67010202 | Lighting equipment | |
| 10 | 67010204 | Lighting equipment | |
| 10 | 67010206 | Lighting equipment | |
| 10 | 67010207 | Set of warning boards | |
| 10 | 67310205 | Work lighting | |
| 10 | 67310319 | Electronic installation | |
| 10 | 57010091 | Protective tilt | |
| 10 | 57010090 | Protective tilt | |
| 10 | 57010089 | Protective tilt | |
| 10 | 321 9914 | Reflector, red | |
| 10 | 321 9915 | Reflector, red | |
| 10 | 373 4260 | Cable | |
| 10 | 37310126 | Rear light | |
| 10 | 37310127 | Rear light | |
| 10 | 37310157 | Basic cable | |
| 10 | 37310196 | Basic cable | |
| 10 | 570 1762 | Lighting unit | |
| 10 | 570 1763 | Lighting unit | |
| 10 | 57010088 | Protective tilt | |
| 10 | 57010087 | Protective tilt | |
| 10 | 57010086 | Protective tilt | |
| 10 | 57010083 | Lighting unit | |
| 10 | 57010082 | Lighting unit | |
| 10 | 57010015 | Warning board | |
| 10 | 57010014 | Warning board | |
| 11 | 67310290 | Operation terminal | |
| 11 | 67310198 | Operation terminal | |
| 11 | 67310197 | Holder wheel sensor | |
| 11 | 67310194 | D-GPS receiver | |
| 11 | 67310100 | Section Control | |
| 11 | 67310099 | Parallel driving system | |
| 11 | 67310089 | Cable form | |
| 11 | 67310088 | Cable form | |
| 11 | 67310073 | CCI.Control | |
| 11 | 67310291 | Cable | |
| 11 | 67310292 | Supplementary set | |
| 11 | R18 0156 | Multifunctional handle | |
| 11 | 699 6721 | Speed sensor | |
| 11 | 699 6714 | Operation terminal | |
| 11 | 68310061 | Angle sensor Lifting | |
| 11 | 67310317 | Electronic installation | |
| 11 | 67310316 | Electronic installation | |
| 11 | 67310315 | Electronic installation | |
| 11 | 67310314 | Electronic installation | |
| 11 | 67310294 | Holder | |
| 11 | 67310071 | CCI.Courier | |
| 11 | 67310068 | Supplementary set | |
| 11 | 67310067 | Camera monitoring | |
| 11 | 57310507 | Dummy plug | |
| 11 | 57310278 | Holder | |
| 11 | 57310241 | Dongle | |
| 11 | 57310199 | Connecting cable | |
| 11 | 57310198 | Connecting cable | |
| 11 | 57310197 | Connecting cable | |
| 11 | 57310196 | Connecting cable | |
| 11 | 57310195 | Connecting cable | |
| 11 | 573 6172 | Connection cable | |
| 11 | 57310549 | Operation terminal | |
| 11 | 57310586 | Dongle | |
| 11 | 67310066 | Switch box | |
| 11 | 67310065 | f. Fahrtrichtung | |
| 11 | 67310064 | D-GPS receiver | |
| 11 | 67310063 | GSM-Box | |
| 11 | 673 6218 | Camera monitoring | |
| 11 | 673 6210 | Operation terminal | |
| 11 | 673 6207 | Joystickbox | |
| 11 | 673 4982 | Holder | |
| 11 | 673 4981 | Holder | |
| 12 | 68310072 | Track marker disc | |
| 12 | 68310073 | Track marker disc | |
| 12 | 68310074 | Track marker disc | |
| 12 | 68310075 | Track marker disc | |
| 12 | 68310076 | Track marker | |
| 12 | 68310071 | Track marker | |
| 12 | 68310070 | Track marker | |
| 12 | 58310020 | Track marker | |
| 12 | 58310019 | Track marker | |
| 12 | 58310018 | Track marker | |
| 12 | 58310017 | Track marker | |
| 12 | 547 8883 | Bearing | |
| 12 | 68310077 | Track marker |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
