Каталог запасных частей к технике: Great Plains NP4000-1630. Hydraulic Pump Assembly
1
1
2
3
4
5
5
6
6
7
8
9
9
10
11
11
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
27
28
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | ВАС-53 | ACE PIPE PLUG | |
| 1 | 41120 | ACE 18 NPT PLUT SS | |
| 2 | BAC-12-150-FLG | ACE VOLUTE 1-1/2NPT X 1-1/4NPT | |
| 3 | 803-146С | NUT HEX 3/8-24 PLT | |
| 4 | BAC-24-HYD-SS | ACE 3/8" WASHER | |
| 5 | ВАС-26-150-Р | ACE IMPELLER, VALOX, KEYWAY | |
| 5 | BAC-26-150-CI | ACE IMPELLER, CAST IRON KEYWAY | |
| 6 | BAC-7SC | ACE SILICON CARBIDE & 40160 | |
| 6 | BAC-7V | ACE MECHANICAL, VITON & 401060 | |
| 7 | ВАС-4-150 | ACE O-RING VOLUTE SEAL | |
| 8 | ВАС-14-150-HYD | ACE MOUNTING FRAME (200 SERIES | |
| 9 | 40950 | ACE 3/8X3/4 BOLT | |
| 9 | 40930 | ACE 3/8X3/4 BOLT SS OPTIONAL | |
| 10 | ВАС-54 | ACE PUMP SLINGER | |
| 11 | ВАС-33 | ACE PUMP INTERNAL SNAP RING | |
| 12 | ВАС-37 | ACE PUMP SEALED BALL BEARING | |
| 13 | ВАС-32 | ACE PUMP EXTERNAL SNAP RING | |
| 14 | BAC-32-S | ACE SPACER | |
| 15 | ВАСН-25 | ACE 1/8"X1/8"X1/2" KEY | |
| 16 | BAC-6-HYD-SS | ACE SHAFT, 5/8 DIA, KW & TANG | |
| 17 | S200 | ACE SEAL SPPRT SPCR (200SERIES | |
| 18 | 507-110А | MOTOR, ACE HYD DRV UPDATE KIT | |
| 19 | 41255 | CAP SCREW, 5/16" N.C. x 3-3/4" | |
| 20 | 40160 | ACE O-RING SHAFT SEAL | |
| 21 | RK-FMC-150 | ACE REPAIR KIT FMC-(150 SERIES | |
| 22 | RK-BAC-75-HYD-L | SEAL KIT FOR BAC-75-HYD-296 | |
| 23 | BAC-78-8SAE | REV CK VALVE ASY FOR 831-058C | |
| 24 | 41448 | O-RING ORIFICE INSERT 831-058C | |
| 25 | BAC-80-8SAE | AD RESTRICTOR BODY 831-058C | |
| 26 | BAC-76-HYD | ACE COUPLING FOR HYD MOTOR | |
| 27 | 41875 | O-RING, #8 SAE FITTING | |
| 28 | 829-131С | FLOW LIMITER VALVE- ACE LS206N |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
