Каталог запасных частей к технике: Great Plains NP4000-1630. Fertilizer Plumbing to Tanks
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
14
15
16
16
16
16
17
17
18
18
18
18
19
19
20
21
22
23
23
23
23
23
23
23
24
24
24
24
24
24
24
25
26
27
27
28
28
29
30
31
32
33
34
35
35
36
37
38
39
39
40
41
42
43
44
45
46
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 990-080R | HOSE 3/8 ID 150PSI EPDM | |
| 2 | 830-121С | EL 3/4MNPT X 3/8HB POLYPROP | |
| 3 | 829-105С | VALVE RELIEF 0-150 PSI POLYP | |
| 4 | 830-161С | AD 1 1/2MNPT X 3/4FNPT POLYP | |
| 5 | 829-104С | GAUGE 100 PSI 4IN STAINLESS ST | |
| 6 | 801-071С | SRHMS 5-40X5/8 SS | |
| 7 | 507-040D | GAUGE PROTECTOR TOP | |
| 8 | 816-144С | DIAPHRAGM - GAUGE PROTECTOR | |
| 9 | 818-344С | DECAL NOTICE GAUGE PROTECTOR | |
| 10 | 507-039D | GAUGE PROTECTOR BOTTOM | |
| 11 | 507-034V | GAUGE PROTECTOR ASSY | |
| 12 | 830-192С | AD 1/4MNPT CLOSE X 7/8 SS | |
| 13 | 830-215С | AD 3/4MNPT X 1/4FNPT POLYPROP | |
| 14 | 830-236С | CR 1 1/2FNPT | |
| 15 | 830-045С | AD 1 1/2MNPT POLYPROP | |
| 16 | 830-052С | EL 1 1/2MNPT X 1 1/2FNPT POLYP | |
| 17 | 830-094С | AD 1 1/2MNPT X 1 1/2HB POLYP | |
| 18 | 800-259С | CLAMP WRM DRV#36SS (1.81-2.75) | |
| 19 | 990-181R | HOSE 1 1/2 ID 150PSI EPDM | |
| 20 | 830-279С | AD 1 1/2MNPT X 1 1/2HB H SAVER | |
| 21 | 829-107С | 2" VALVE GASKET | |
| 22 | 830-254С | AD 1 1/2MNPT X 1HB POLYPROP | |
| 23 | 816-161С | GASKET 1 1/2 CAM-LOCK CP EPDM | |
| 24 | 830-351С | CLAMP 2" BANJO FLANGE | |
| 25 | 831-078С | STRAINER BANJO MLST150-80 MESH | |
| 26 | 829-126С | VALVE 1 1/2 MANI 3 WAY BALL | |
| 27 | 502-174D | ANGLE - 1 1/2 B VALVE SUPPORT | |
| 28 | 802-159С | HHCS 5/16-18X1 GR5 | |
| 29 | 804-01ЗС | WASHER LOCK SPRING 3/8 PLT | |
| 30 | 803-195С | NUT HEX 3/8-16 SS | |
| 31 | 804-036С | WASHER FLAT 5/16 SAE PLT | |
| 32 | 804-009С | WASHER LOCK SPRING 5/16 PLT | |
| 33 | 803-008С | NUT HEX 5/16-18 PLT | |
| 34 | 830-155С | EL 1 1/2 FLANGE POLY | |
| 35 | 830-387С | EL 1 1/2 FLANGE 45 DEG POLY | |
| 36 | 830-324С | AD 1 1/2 FLG X 1 1/2 MNPT POLY | |
| 37 | 829-048С | VALVE - 1 1/2FNPT X 2FCL POLYP | |
| 38 | 830-186С | PL 2MCL POLY-GLASS | |
| 39 | 830-325С | EL 1 1/2 FLANGE X 1 1/2HB POLY | |
| 40 | 848-555С | DECAL VALVE SELECTOR | |
| 41 | 802-034С | HHCS 1/2-13X1 1/4 GR5 | |
| 42 | 804-015С | WASHER LOCK SPRING 1/2 PLT | |
| 43 | 803-020С | NUT HEX 1/2-13 PLT | |
| 44 | 407-638Н | HOSE CLAMP WELDMENT | |
| 45 | 407-720D | QUICKFILL MOUNT | |
| 46 | 502-060D | DUST PLUG CHAIN 10 | |
| 47 | 805-010С | PIN HAIR COTTER .094 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
