Каталог запасных частей к технике: Great Plains 3N-4010. 20 Series Opener Body
1
1
2
3
4
5
6
6
7
7
8
9
9
9
9
10
11
12
12
13
14
15
16
17
18
18
19
20
21
22
22
23
24
24
25
26
27
28
29
29
30
31
32
32
33
34
34
35
36
37
38
39
40
41
42
43
44
45
45
46
47
48
49
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 817-530C | 3N-40 SEED TUBE NO SENSOR HOLE | |
| 2 | 198-615H | 20 SERIES SINGULATING OPENER | |
| 3 | 805-063C | PIN COTTER 3/32 X 1 LONG | |
| 4 | 805-296C | PIN CLEVIS 1/4X1 31/64 USBL | |
| 5 | 198-241D | SEED FLAP MOUNTING CLIP, SING | |
| 6 | 817-349C | SEED FLAP, UHMW, LONG | |
| 6 | 816-302C | SEED FLAP, RUBBER, SEED-LOK | |
| 7 | 107-133S | RPBY | |
| 8 | 107-138S | DD W/205 BRG-PLD FLNG-4MM | |
| 9 | 804-040C | WASHER MACH | |
| 10 | 802-228C | HHCS | |
| 11 | 805-335C | PIN ROLL | |
| 12 | 812-309C | SCRAPER-SPREADER 10-20SER 2003 | |
| 12 | 198-491H | SCRAPER-SPREADER 10-20 SER | |
| 13 | 800-213C | RIVET,BUTTON HEAD | |
| 14 | 890-466C | HSG RIBB FLG | |
| 15 | 188-001V | BRG | |
| 16 | 820-256C | FLAT DISK BLADE-4MM THICK | |
| 17 | 198-202D | 20 SER OPNR CAM PIN | |
| 18 | 800-118C | SNAP RING EXT 5/8 .050 T | |
| 19 | 298-324S | RPBY 812-328C | |
| 20 | 812-302C | CASTING - STAINLESS T-HANDLE | |
| 21 | 803-307C | NUT HEX 7/16-20 GR8 | |
| 22 | 804-014C | WASHER LOCK | |
| 23 | 198-201D | 20 SER OPNR PW CAM | |
| 24 | 817-083C | PRESS WHEEL ARM PIVOT BUSHING | |
| 25 | 807-172C | SPRING COMP 5/8 OD X 1 3/4 LG | |
| 26 | 804-012C | WASHER FLAT | |
| 27 | 805-067C | PIN COTTER | |
| 28 | 198-265D | 20P SIDE DEPTH WHEEL ARM | |
| 29 | 198-998S | 20P ELIMINATOR BUSHING ASSY | |
| 30 | 804-022C | WASHER LOCK SPRING | |
| 31 | 802-179C | HHCS 5/8-11X2 1/2 GR5 NYL | |
| 32 | 198-057S | 2X13 DEPTH WHEEL ASSY | |
| 33 | 802-352C | HFSS 5/16-18X1/2 GR5 | |
| 34 | 803-043C | NUT HEX WHIZ 5/16-18 PLT | |
| 35 | 814-082C | 2X13 D.W. OUTER RIM HALF | |
| 36 | 814-083C | 2X13 SIDE DEPTH TIRE | |
| 37 | 198-183D | 20 SER SIDE DEPTH WL STIFF PLT | |
| 38 | 814-081C | 2X13 D.W. INNER RIM HALF | |
| 39 | 802-694C | HHCS 7/16-20 2 3/4 GR8 | |
| 40 | 122-257H | SEP ANDFERT TUBE 10-20SER 1999 | |
| 41 | 800-001C | GREASE ZERK STRAIGHT | |
| 42 | 804-195C | WASHER FLAT 1.31ODX.65IDX.188T | |
| 43 | 802-430C | HHCS 5/8-11X2 GR5 NYL | |
| 44 | 802-092C | RHSNB | |
| 45 | 816-723C | U CUP SEAL | |
| 46 | 298-001D | 20P DEPTH WHL OUTER BUSHING | |
| 47 | 198-266D | 20P DEPTH WHL ECCENTRIC BUSHNG | |
| 48 | 198-956K | 20 SER OPENER T-HANDLE SUBASSY | |
| 49 | 822-095C | BRG INS |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
