Каталог запасных частей к технике: Great Plains 2S-2600, 2S-2600F. Fertilizer Tray
1
2
3
4
5
6
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
24
25
26
26
27
28
29
30
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 141-084D | TRAY BEARING SPACER | |
| 2 | 175-102H | FERT BEARING RETAINER | |
| 3 | 191-001D | HEX BORE BUSHING | |
| 4 | 191-002D | MF FERT HEX BORE PLASTIC BUSH | |
| 5 | 191-018D | MF FERT STAR RETAINER SIDE PLT | |
| 6 | 175-183H | FERT TRAY WELDMENT | |
| 6 | 175-182H | FERT TRAY WELDMENT | |
| 6 | 175-184H | FERT TRAY WELDMENT | |
| 7 | 175-338D | FERT TRAY ADAPTER PANEL | |
| 8 | 175-341D | AGITATOR SHAFT | |
| 9 | 800-032C | LATCH STRIKE | |
| 10 | 800-012C | RIVET SS | |
| 11 | 801-009C | SCREW SET | |
| 12 | 802-079C | HHCS | |
| 13 | 802-092C | RHSNB | |
| 14 | 802-148C | HFSS | |
| 15 | 802-252C | RHSNB | |
| 16 | 802-633C | RHSNB | |
| 17 | 803-006C | NUT-HEX | |
| 18 | 803-008C | NUT HEX | |
| 19 | 803-014C | NUT HEX | |
| 20 | 803-088C | NUT HEX LOCK | |
| 21 | 804-006C | WASHER LOCK SPRING | |
| 22 | 804-009C | WASHER LOCK SPRING | |
| 23 | 804-013C | WASHER LOCK SPRING | |
| 24 | 808-086C | HEXBORE W/ SS | |
| 25 | 816-292C | VINYL FERT DEW SHIELD | |
| 26 | 817-053C | POINT FERT METERING WHEEL | |
| 27 | 817-323C | NYLON RATCHET | |
| 28 | 822-083C | BRG FLG | |
| 29 | 890-026C | FELT SEAL | |
| 30 | 804-048C | WASHER MACH | |
| 31 | 800-030C | LATCH FERT TRAY DOOR |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
