Каталог запасных частей к технике: Great Plains 1200, 1500, 2000. Gauge Wheel Drive

1

2

3

4

5

6

7

7

8

9

10

10

11

12

12

12

13

13

14

15

16

17

18

19

20

20

20

20

21

21

21

21

22

23

24

25

26

27

27

28

29

30

30

31

32

33

33

34

34

35

36

36

37

Позиция на иллюстрации	Заводской номер детали		Название детали
1	120-199D		SPACER TUBE 5 1/32
2	120-200D		SPACER TUBE 1 21/32
3	120-201D		SPACER TUBE 2 47/64
4	802-044C		HHCS 1/2-13X4 GR5
5	817-025C		NO
6	803-036C		NUT HEX JAM
7	804-017C		WASHER FLAT
8	803-178C		NUT NYLOCK JAM NUT 1/2-13
9	808-142C		SPKT 40B19 X 3/4 HEX BORE
10	808-142C		SPKT 40B19 X 3/4 HEX BORE
10	808-139C		SPKT 40B29 X 3/4 HEX BORE
11	120-204D		GAUGE WHEEL JACK SHAFT 3/4 HEX
12	890-295C		ACREMETER 20' 11L X 15
12	890-003C		ACRE METER 15'
12	890-001C		ACRE METER 12'
13	136-089D		CHAIN RL #40 81 PITCHES
13	809-110C		REP BY 136-089D
14	805-067C		PIN COTTER
15	804-016C		WASHER FLAT
16	817-025C		NO
17	120-212H		TWO PIN IDLER WELDMENT
18	802-258C		HHCS 1/2-13X1 GR5
19	803-019C		NUT LOCK
20	120-239D		REPLACED BY 808-140C
20	808-140C		SPKT 40B28 X2 BORE W/5/16 HOLE
20	120-238D		REPLACED BY 808-097C
20	808-097C		SPKT
21	809-135C		REP BY 136-106D
21	136-106D		CHAIN RL #40 111 PITCHES
21	809-062C		REPD BY 136-058D
21	136-058D		CHAIN RL #40 102 PITCHES
22	805-125C		PIN ROLL 5/16 X 2 1/2 PLT
23	118-260A		3PT LOUP ACREMETER
24	118-071D		3PT ACREMETER SWITCH MOUNT
25	168-492D		ACREMETER MOUNT
26	540005-1		3/4 HEX SNAP-ON ACTUATOR
27	801-064C		SHCS 1/4-20 X 2 1/4
28	802-128C		HHCS 1/2-13X2 GR5
29	803-014C		NUT HEX
30	803-064C		NUT HEX
31	804-013C		WASHER LOCK SPRING
32	804-036C		WASHER FLAT
33	804-043C		WASHER LOCK
34	804-088C		WASHER FLAT
35	806-051C		U-BOLT 3/8-16 X 6 1/32 X 7
36	823-423C		ELECTRONIC ACRE METER
37	823-434C		HARNESS EXT. 10' 2 PIN WP
