Каталог запасных частей к технике: Gaspardo ZENO. ZENO 24-28-32
1
2
3
4
4
5
5
6
6
7
7
8
9
9
10
11
12
12
13
14
15
16
17
17
18
19
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | T010.316 | STAINLESS STEEL HOPPER 1600 L. 8 Z95 | |
| 2 | T013.211 | SIDE HOPPER CROSS BRACE SP 95 (LEFT) | |
| 3 | T013.212 | SIDE HOPPER CROSS BRACE SP 95 (RIGHT) | |
| 4 | V003.171 | ST.STEEL CUP SQUARE SCREW 10X25 UNI 603 | |
| 5 | R005.086 | NYLON WASHER 12 X 24 X 2 | |
| 6 | R005.013 | ST. STEEL FLAT WASHER DM10 UNI6592 | |
| 7 | D001.005 | ST. STEEL HEXAGON NUT DM 10 UNI 5588 | |
| 8 | T013.188 | REAR HOPPER SUPPORT CROSS BRACE SP 95 | |
| 9 | T008.108 | HOPPER FIXING TIE ROD SP 70-95 | |
| 10 | R005.038 | ST.STEEL FLAT WASHER DM 14 UNI 6592 | |
| 11 | D001.018 | GALVANIZED HEXAGON NUT UNI 5588 | |
| 12 | T008.109 | HOPPER FIXING TIE ROD SP 70-95 | |
| 13 | O003.221 | LIFT HORN (STAINLESS STEEL IMPLEMENTS) | |
| 14 | S012.062 | HOPPER INSPECTION PLEXIGLASS DOOR | |
| 15 | I006.021 | WING NUT AND BOLT M8 F | |
| 16 | C007.014 | CHAIN MM22 ZN | |
| 17 | G001.008 | SCREW HOOK D6 | |
| 18 | P004.116 | TILTING HOPPER PIN Z/J K2 | |
| 19 | C019.005 | ST. STEEL MOULDED SPLIT PIN DM 4X90 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
