Каталог запасных частей к технике: Gaspardo ZENO. ZENO 18-24-28-32
1
1
2
2
3
4
5
5
6
7
7
8
8
9
10
11
11
12
12
13
13
13
13
13
13
13
13
14
15
16
16
16
16
17
17
18
19
19
20
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | C013.024 | CYLINDER 20 C62 NEW TYPE | |
| 2 | C019.015 | STAINLESS STEEL SPLIT PIN 2,5 X 25 | |
| 3 | D001.006 | STAINLESS STEEL HEXAGON NUT DM8 UNI 5588 | |
| 4 | D001.071 | ST.STEEL HEXAGON NUT DM10 UNI 5589 | |
| 5 | F007.003 | GALVANIZED FORK M 10 X 40 (YELLOW) | |
| 6 | P004.043 | GALVANIZED PIN DM 10 X 25 (YELLOW) | |
| 7 | R001.001 | ADAPTER DOUBLE SCREW 1/4"-1/4" | |
| 8 | R001.009 | ADAPTER 1/4" 90° | |
| 9 | R001.014 | ADAPTER DOUBLE SCREW 1/2"-1/4" | |
| 10 | R001.023 | GALVANIZED ADAPTER TI FFF 1/4" | |
| 11 | R001.026 | ORIENTABLE ADAPTER 1/4"M 1/4"F | |
| 12 | R005.017 | ST.STEEL FLAT WASHER DM 8 UNI 6592 | |
| 13 | R005.030 | COPPER FLAT WASHER 1/4" | |
| 14 | S008.248 | HYDRAULIC CONTROL CLAMP | |
| 15 | S008.274 | HYDRAULIC CONTROL CLAMP | |
| 16 | T015.027 | PIPE 1/4" R1AP-AS 1/4"M 1/4"F 90° L3200 | |
| 17 | T015.032 | PIPE 1/4"R1AP-AS 1/4"M 1/4"F L=2000 | |
| 18 | V003.008 | ST.STEEL HEXAGON HEAD SCREW 8X20 UNI5739 | |
| 19 | V004.002 | COCK VALVE 1/4" (2 WAYS WITH LEVER) | |
| 20 | V004.003 | VALVE WITH MALE COUPLING 1/2" WITH CAP |
