Каталог запасных частей к технике: Gaspardo SP DORADA. PLASTIC FERTILIZER TANKS
1
2
2
3
3
4
4
5
6
7
7
8
9
11
11
12
13
14
14
14
15
16
17
18
19
20
21
22
23
23
23
24
25
26
26
27
28
30
31
31
31
31
32
33
34
35
36
36
36
36
37
37
38
39
39
40
41
42
43
44
44
44
45
46
47
48
49
50
51
52
53
53
54
55
56
57
58
59
60
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 14830390 | BEARING SQUARE HOLE | |
| 2 | 15271540 | AXIS AGITATOR DX SERB. 1100 fully QUALIFIED | |
| 2 | 20860121 | AXIS AGITATOR DX SERB. 850 COMPLETE | |
| 3 | 15271550 | AXIS AGITATOR SX SERB. 1100 fully QUALIFIED | |
| 3 | 20860122 | AXIS AGITATOR SX SERB. 850 COMPLETE | |
| 4 | 15470580 | TANK COVER 850 | |
| 4 | 15471920 | COVER TANK 1100 | |
| 5 | 15471930 | PROTECTION | |
| 6 | 15471990 | SUPPORT SCREW | |
| 7 | 15472760 | GRID TANK PLASTIC 850 | |
| 7 | 15473130 | GRID TANK PLASTIC 1100 | |
| 8 | 15472770 | DISTRIBUTOR FERTILIZER SPREADER PLASTIC | |
| 9 | 15472780 | CAP SPREADER, PLASTIC | |
| 10 | 19002710 | PROTECTION REFERRAL FERTILIZER | |
| 11 | 19004470 | TANK MANURE 850 INIETT PLASTIC | |
| 11 | 19003060 | TANK MANURE 1100 PLASTIC | |
| 12 | 19002850 | PROTECTION PINION | |
| 13 | 19002920 | THE BODY DISTRIBUTOR FERTILIZER X CEILING. PLASTIC | |
| 14 | 20860012 | SLEEVE UNION L. 500 | |
| 14 | 20910044 | SLEEVE UNION L. 1375 | |
| 14 | 20910045 | SLEEVE UNION L. 1180 | |
| 15 | 20860052 | REGULATOR OPENING | |
| 16 | 20860086 | GEAR 1/2 Z-12 F. Q. | |
| 17 | 20860088 | GEAR 1/2 Z-12 F. T | |
| 18 | 20860090 | AXIS TRANSMISSION L. 1460 | |
| 19 | 20860093 | ADJUSTMENT SCREW | |
| 20 | 20860106 | DISPENSER FERTILIZER COMPLETE | |
| 21 | 20860126 | KIT GEARS DISTRIBUTOR FERTILIZER (2+2 PCS) | |
| 22 | 19005040 | BUSHING AXLE FERTILIZER SPREADER | |
| 23 | 20890115 | CLAMP PLASTIC COMPLETE | |
| 24 | 20970097 | WASHER 32X3X4,5 | |
| 25 | 20970125 | WASHER 28X2,5X6,5 | |
| 26 | 22220073 | WASHER 28X0,3X16,5 | |
| 27 | 22230094 | BEARING SUPPORT | |
| 28 | 22250287 | SPACER SLEEVE | |
| 29 | 41602016 | SCREW 6 X60 5737 8.G ZN | |
| 30 | 41602024 | SCREW 8 X40 5737 8.G ZN | |
| 31 | 41605015 | SCREW 6 X16 5739 8.G ZN | |
| 32 | 41605027 | SCREW 8 X16 5739 8.G ZN | |
| 33 | 41605041 | SCREW 10X25 5739 8.G ZN | |
| 34 | 41982005 | SCREW 4,2X38 DIN 7981 | |
| 35 | 41984001 | SCREW AUTOF.4,2X9,5T.And.TAGF.RO | |
| 36 | 43530004 | NUT 6 5588 6.8 ZN | |
| 37 | 43530006 | NUT 8 5588 6.8 ZN | |
| 38 | 43549003 | NUT TRISTOP M10 | |
| 39 | 44953002 | WASHER D6 UNI 6592 ZN | |
| 40 | 44953003 | WASHER D8 UNI 6592 ZN | |
| 41 | 46966072 | PLUG EL.5 X20 DIN 1481 | |
| 42 | 46966079 | PLUG EL.5 X36 DIN 1481 | |
| 43 | 46966099 | PLUG EL.6 X30 DIN 1481 | |
| 44 | 53229001 | SEALS LIP DE100 | |
| 45 | 57158001 | APRIL.CAT.1/2 ISO 083 32MA.TR. | |
| 46 | 61209001 | TUBE ASPIREX 35 COLOR BLACK | |
| 47 | 65336025 | SPRING SPEC.ZN HOSE | |
| 48 | 65336055 | SPRING SPEC.ADJUSTING FERTILIZER | |
| 49 | 65336062 | SPRING SPEC.SLIDE DISTRIBUTOR SPREADERS | |
| 50 | 65336064 | SPRING SPEC.AUGER DX FERTILIZER | |
| 51 | 65336065 | SPRING SPEC.AUGER SX FERTILIZER | |
| 52 | 65338043 | SPRING COMP.ZN TANK | |
| 53 | 66248121 | BUSHING WITH FLANGE | |
| 54 | 66248125 | ADJUSTING RING | |
| 55 | 66248178 | SLIDE DISTRIBUTOR FERTILIZER SPREADER | |
| 56 | 66248207 | CHAIN SPREADER | |
| 57 | 66248218 | SPACER SPREADER | |
| 58 | 67008060 | THREADED CAP CEILING.PLASTIC | |
| 59 | 19700821 | DECAL.TABLE DISTRIBUTION OF MANURE | |
| 60 | 18701500 | WASHER 29,5 X38 X0,3 |
