Каталог запасных частей к технике: Gaspardo MT. REAR COMPRESSION WHEELS
2
3
4
4
5
6
7
8
8
9
10
11
12
13
14
15
16
16
16
17
18
19
19
20
21
22
23
24
25
25
26
27
28
29
29
30
30
31
32
33
34
35
36
37
37
38
39
40
41
42
43
43
43
44
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | F01410037 | PLANE WASHER D.6 | |
| 2 | F06120439 | Coppia cerchi ruota | |
| 3 | F06120438 | Coppia cerchi ruota | |
| 4 | F04010131 | BEARING 6004 2RS EX. SKF | |
| 5 | F01220048 | NUT M12X1,75 D980 8 ZN | |
| 6 | G19703480 | PLATE | |
| 7 | F02250066 | POP RIVET 3X9 ALUMINIUM | |
| 8 | G66349003 | BUSHING- SINTERED | |
| 9 | G18903741 | HANDLE STOP SPRING MAGICA 2004 | |
| 10 | G15226280 | INDICATORE PROFONDITA' COMPL | |
| 11 | F01410076 | WASHER D12 U6592 ZN | |
| 12 | G15220960 | ADJUSTMENT HANDLE | |
| 13 | G15224611 | ASS.SUPP.RUOTE COMPRESSIONE | |
| 14 | F01020170 | SCREW M12X1,75X100 5737 8.8 ZN | |
| 15 | G22505059 | REAR HUB | |
| 16 | F01230022 | NORM.SELF-LOCKING NUT 6 GALVAN | |
| 17 | G15226610 | GASKET SET FOR WHEEL V1 | |
| 18 | G15226620 | SEAL&SPACER-KIT FOR WHEEL V2 | |
| 19 | F01020042 | BOL.M6X1X50 U5737 8.8 ZG | |
| 20 | G15226270 | MOLLA COMPL. | |
| 21 | F01020406 | BOLT M6X25 | |
| 22 | F06120076 | RUBBER WHEEL 1'X12' PLA.2 BEAR | |
| 23 | F06120181 | RUBBER RING 1X12' | |
| 24 | F06120075 | RUBBER WHEEL 2'X13' PLA.2 BEAR | |
| 25 | F06120165 | RUBBER RING 2X13' | |
| 26 | F02200227 | SPLIT PIN 5X30 1336 GALVAN. | |
| 27 | G15224790 | COMPL. REAR CAST IRON WHEEL | |
| 28 | G15224800 | REAR WHEEL | |
| 29 | G16242190 | BEARING SUPPORT | |
| 30 | F04010156 | BEARING D20 D47 B14 6204 2RSH | |
| 31 | G15224810 | BUSH 20.5X25X3 | |
| 32 | G15423850 | STEEL WHEEL BUSH | |
| 33 | F01040091 | SCREW 8X20 5931 8.G ZN | |
| 34 | F01220022 | NUT M8X1,25 D980 8 ZN | |
| 35 | F06120440 | Ruota da | |
| 36 | F06120441 | Coppia cerchi ruota | |
| 37 | F04100149 | Bearing | |
| 38 | F06120405 | Rubber wheel | |
| 39 | G19006290 | Coppia cerchi ruota | |
| 40 | G19006280 | Rubber ring | |
| 41 | F01020039 | Bolt | |
| 42 | F01200232 | DADO M6X1 U5588 6.8 ZN | |
| 43 | F03011082 | Lip seal | |
| 44 | F03011083 | Lip seal |
