Каталог запасных частей к технике: Gaspardo Feraboli Entry 150. Rear gate
1
2
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
12
12
13
13
13
13
14
14
14
15
15
15
16
16
17
17
18
19
19
20
21
21
22
23
23
23
23
24
25
26
27
27
28
28
29
30
31
32
32
32
32
33
34
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
49
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 7SP0311 | Tailgate frame entry 150 | |
| 2 | 7S00158 | Idle shaft | |
| 3 | 1300081 | Spacer | |
| 4 | 7SP0281 | Idle gear | |
| 5 | 1710062 | Seeger ring | |
| 6 | 2043514 | Bearing | |
| 7 | 2040002 | Bearing | |
| 8 | 13P0146 | Shaft guide support | |
| 9 | 0190860 | Screw | |
| 10 | 0920208 | Nut | |
| 11 | 05P0006 | Endless screw | |
| 12 | 1328313 | Spacer | |
| 13 | 1534416 | Shim | |
| 14 | 1534415 | Shim | |
| 15 | 0710620 | Nut | |
| 16 | 13P0142 | Bush | |
| 17 | 18P0010 | Tensioning spring | |
| 18 | 13P0143 | Washer | |
| 19 | C6P0324 | Lock | |
| 20 | 0523421 | Special screw | |
| 21 | 1421230 | Washer | |
| 22 | C3P0127 | Rear crosspiece entry | |
| 23 | B00920412 | Nut | |
| 24 | 0181025 | Screw | |
| 25 | 0545790 | Self-locking nut | |
| 26 | C3P0297 | Back case | |
| 27 | 1430820 | Washer | |
| 28 | 0180820 | Screw | |
| 29 | 0180830 | Screw | |
| 30 | B07SP0271 | Right hinge | |
| 31 | B07SP0272 | Left hinge | |
| 32 | B01515797 | Fifth wheel | |
| 33 | B0C6P0205 | Shim | |
| 34 | B00171250 | Screw | |
| 35 | B0C6P0206 | Shim | |
| 36 | 1700105 | Snp ring | |
| 37 | 7SP0309 | Right tailgate case | |
| 38 | 7SP0310 | Left tailgate case | |
| 39 | 0370001 | Screw | |
| 40 | 0370001 | Screw | |
| 41 | 7C00001 | Balecounter | |
| 42 | 03f0000 | Screw | |
| 43 | 1800023 | Silent block | |
| 44 | 3300005 | Chain | |
| 45 | 0180620 | Screw | |
| 46 | 1420615 | Washer | |
| 47 | 0920106 | Nut | |
| 48 | 0920208 | Nut | |
| 49 | 1430820 | Washer | |
| 50 | C2P0386 | Spacer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
