Каталог запасных частей к технике: Gaspardo ALITALIA. SIMPLE DISC REDUCERS
1
2
3
4
5
6
7
8
9
9
9
9
9
10
10
10
11
11
11
11
12
12
12
13
14
15
16
17
18
19
20
21
21
22
23
23
24
25
26
27
28
29
30
30
31
31
31
31
32
33
33
34
35
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
55
57
58
58
59
59
60
60
61
62
63
64
65
65
66
67
68
69
70
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | F01020042 | BOL.M6X1X50 U5737 8.8 ZG | |
| 2 | F01420037 | ROS.M6 6,4X24X2 U6593 ZN | |
| 3 | F01030060 | Bolt | |
| 4 | G15821110 | Seed cover supp. Bushing | |
| 5 | G16248622 | LEFT DEPTH LIMITER | |
| 6 | G19203970 | LEFT CUTTER | |
| 7 | F01220255 | Nut-tristop | |
| 8 | G16045700 | REINFORCED & LONG DS ELEMENT | |
| 9 | F01060013 | Bolt | |
| 10 | G16043880 | SOILSCRAPER DS ZN | |
| 11 | F01220011 | NUT M6X1 D980 8 ZN | |
| 12 | F01230022 | NORM.SELF-LOCKING NUT 6 GALVAN | |
| 13 | G16040863 | ZAMA LOCK DUST SEAL 8ZN | |
| 14 | F01230034 | SELF LOCK.NUT M8X1,25 D982 8ZN | |
| 15 | G16040921 | FLANGE w/ BEARING | |
| 16 | G16040820 | DISC SPINDLE | |
| 17 | G16043890 | DISC OPENER D.328 SP.2,5 | |
| 18 | F03010576 | GASKET OR 033 DOWTY | |
| 19 | G19003422 | KIT BEARING FLANGE+OUTER DISC | |
| 20 | F01040501 | SCREW M8X1,25X25 D7984 8.8ZN | |
| 21 | F01220048 | NUT M12X1,75 D980 8 ZN | |
| 22 | G16045690 | REINFORCED & SHORT DS ELEMENT | |
| 23 | F01020168 | SCREW M12X1,75X90 U5737 8.8 ZN | |
| 24 | G18904240 | SPRING | |
| 25 | G19203980 | RIGHT CUTTER | |
| 26 | G16248782 | RIGHT DEPTH LIMITER | |
| 27 | F04010131 | BEARING 6004 2RS EX. SKF | |
| 28 | F06120409 | RUBBER WHEEL 250X42L PLA.2BEAR | |
| 29 | G16249390 | SOIL SCRAPER SUPPORT SUP.RIGHT | |
| 30 | G18802740 | BUSHING 25X12X63,5 | |
| 31 | F04150034 | BEARING FLANGED 25X28X16 | |
| 32 | G16248351 | FURROW SUPPORT COMPL. | |
| 33 | F01100011 | GREASE NIPPLE M6X1 7663-A ZN | |
| 34 | G16043820 | BUSHING D10XD29-35 ZN | |
| 35 | F01410037 | PLANE WASHER D.6 | |
| 36 | G16340810 | FIXING STRIKER PLATE | |
| 37 | G16249040 | BLADE SUPPORT DS DX IX | |
| 38 | G16249050 | BLADE SUPPORT DS SX IX | |
| 39 | G16249130 | R.LOW SOILSCRAPER SUPPORT ZN | |
| 40 | G16249410 | SOIL SCRAPER SUPPORT SUP.LEFT | |
| 41 | G16249140 | LOW.MUDSCRAPER SUPP.LEFT | |
| 42 | G65336001 | SPEC SPRING ZN MAN. PIPE CLAMP | |
| 43 | G19005340 | JOINT SLEEVE | |
| 44 | F02300020 | String fasten.straps | |
| 45 | G19004320 | COUPLING SLEEVE | |
| 46 | F02300021 | STRING FASTEN.STRAPS 40/60 H.8 | |
| 47 | G07000126 | SLIDE LINKAGE HOUSING | |
| 48 | G16340860 | PLATE SPRING TIGHTENER | |
| 49 | G16340840 | PLATE INTERM. | |
| 50 | G18904360 | SPRING | |
| 51 | F01020436 | SCREW M8X1,25X20 U5739 8.8 ZN | |
| 52 | F01410051 | WASHER M8 8,4X17X1,6 U6592 ZN | |
| 53 | F01220022 | NUT M8X1,25 D980 8 ZN | |
| 54 | F01440081 | RAISING WASHER 37X47X0.1 | |
| 55 | F04010309 | BEARING D30 D47 B9 61906 2RS | |
| 56 | G19003422 | KIT BEARING FLANGE+OUTER DISC | |
| 57 | F01060086 | BOLT 10X70 5732 4.6 GALVANIZED | |
| 58 | G16045740 | GALVAN. PIN D.10X32 | |
| 59 | F02200342 | Spring split pin | |
| 60 | F01220033 | NUT M10X1,5 D980 8 ZN | |
| 61 | G16043830 | BUSHING D10XD29-13 ZN | |
| 62 | G16043462 | WHEEL SUPPORT | |
| 63 | G16045500 | SOIL SCRAPER SUPPORT | |
| 64 | F01020404 | BOLT 6X20 5739 8.G GALVANIZED | |
| 65 | F05100195 | COVER 36,51X25,41 NERO | |
| 66 | G16043390 | RIGHT LATERAL SUPPORT | |
| 67 | G16341340 | OUTER RIGHT ELEMENT TIE ROD | |
| 68 | F01230048 | Nut | |
| 69 | F20110715 | Striker | |
| 70 | G16043320 | SHORT FURROW SUPP.COMPL. |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
