Каталог запасных частей к технике: Foton TA60. Rear Driving Wheel Assembly
1
1
1
2
2
2
3
3
3
4
4
4
5
6
6
7
7
8
8
8
9
10
11
11
11
12
12
13
14
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | GB/T 2979-1999 | cover tire | |
| 1 | GB/T 2979-1999 | cover tire | |
| 1 | GB/T 2979-1999 | cover tire | |
| 2 | GB/T 2979-1999 | cover tire | |
| 2 | GB/T 2979-1999 | cover tire | |
| 2 | GB/T 2979-1999 | cover tire | |
| 3 | GB/T 6170-2000 | Nut | |
| 3 | GB/T 6171-2000 | Nut | |
| 4 | GB/T 93-1987 | Spring washer | |
| 5 | GB/T 97.1-1985 | Plain washer | |
| 6 | FT550.34.105 | wear,rear driving wheel | |
| 6 | FT650.34.105 | spoke | |
| 7 | W14LX30-3 | screw M16*80 | |
| 7 | W14LX30-3 | screw M16*80 | |
| 8 | W12X30A-1 | rim weldment | |
| 8 | W10X28 | rim weldment | |
| 8 | W13X28.B-1 | rim weldment | |
| 9 | FT650.34.102 | rear balance weight bolt | |
| 10 | GB/T 95-1985 | Plain washe | |
| 11 | FT650.34.101 | rear balance weight | |
| 12 | FT650.34.103 | rear balance weight bolt | |
| 13 | FT650.34.104 | Washer | |
| 14 | GB/T 5783-2000 | Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
