Каталог запасных частей к технике: Foton TA60. Front Driving Axle Assembly-4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 504.31.170-1 | Rear sleeve | |
| 2 | 704.31.171 | Bearing housing of rear swing shaft | |
| 3 | GB1152-1989 | Oil cup M10x1 | |
| 4 | 504.31.150 | Rear sleleton oil sealing | |
| 5 | 504.31.152 | Dust cap for rear swing shaft | |
| 6 | 504.31.159-1 | Locking nut | |
| 7 | 504.31.157-2 | Spacer ring | |
| 8 | HG4-692-67 | oil sealing SG50*72*12 | |
| 9 | GB1235-1976 | O-seal ring | |
| 10 | GB/T 308-1989 | Steel ball | |
| 11 | 504.31.153-1 | spacer sleeve | |
| 12 | GB/T 297-1994 | tapered roller bearing | |
| 13 | 504.31.154-2 | Bearing housing of drive conical gear | |
| 14 | 504.31.156 | adjusting shim | |
| 15 | GB1235-1976 | O-seal ring | |
| 16 | GB/T 297-1994 | tapered roller bearing | |
| 17 | 504.31.155-2 | Driving conical gear |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
