Каталог запасных частей к технике: DongFeng 504G3. Fuel System
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | GB/T5782-2000-M6x25 | Bolt M6x25 | |
| 2 | GB/T859-1987-6 | Washer 6 | |
| 3 | N85T-32001D | Injection adapter | |
| 4 | N85Q-18005 | Injection pump timing gear adapter | |
| 5 | GB/T3452.1-2005-77.5x2.65 | Oil seal 77.5x2.65 | |
| 6 | 4L68-180003 | Injection pump end cover | |
| 7 | N85-15500(A ) | Fuel feed pump inlet connection | |
| 8 | 4G33-181000 | Injection pump | |
| 9 | N485Q-18007B-1 | Electronic flame support | |
| 10 | N485-15400 | Fuel feed pump outlet pipe | |
| 11 | N485-15300 | Fuel filter outlet pipe | |
| 12 | 4G33-182000 | Injection pump oil pipe | |
| 13 | JB/T6013-2000-8 | Washer8 | |
| 14 | JB/T6013-2000-M8x1 | Hollow bolt M8x1 | |
| 15 | N485-28000B | Fuel filter | |
| 16 | GB/T859-1987-8 | Washer 8 | |
| 17 | GB/T5782-2000-M8x25 | Bolt M8x25 | |
| 18 | 4L68-184000A-1 | Electronic flame | |
| 19 | 4L68-151000-3 | Injector fuel return pipe part | |
| 20 | 4L68-150003 | Fuel return main pipe | |
| 21 | 4L68-250000 | Injector | |
| 22 | 4G33-141000 | 1st cylinder high pressure fuel pipe | |
| 23 | 4G33-142000 | 2nd cylinder high pressure fuel pipe | |
| 24 | 4G33-143000 | 3rd cylinder high pressure fuel pipe | |
| 25 | 4L68-150002 | Fuel return pipe | |
| 26 | 4G33-144000 | 4th cylinder high pressure fuel pipe | |
| 27 | 4L68-150001-3 | Injector fuel return cover | |
| 28 | 4L88-145000 | Clamp parts with two holes | |
| 29 | 4L88-146000 | Clamp parts with three holes |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
