Каталог запасных частей к технике: DongFeng 504G3. Electrical System 504G3.48A.001
1
2
3
4
5
6
7
8
9
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
24
24
24
25
26
27
28
29
30
31
32
33
34
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 504G3.48.016 | Elastic cable paper | |
| 2 | 6-QW-80L | Battery | |
| 3 | 254G3.48.019 | Electrical source switch | |
| 4 | 504G3.48.017 | Elastic cable paper | |
| 5 | QD157A | Starting motor | |
| 6 | 504G3.48.021 | Steering lamp | |
| 7 | 504G3.48.104 | Oil pressure sensor | |
| 8 | 504G3.48.103 | rotation speed senser | |
| 9 | 504G3.48A.012B | Main wiring harness | |
| 9 | 504G3.48A.012A | Main wiring harness | |
| 9 | 504G3.48A.012-1 | Main wiring harness | |
| 10 | 504G3.48.020 | Fuse box wiring harness | |
| 11 | 504G3.48.027 | Caution light swich cover plate | |
| 12 | 504G3.48A.104A | Approach switch | |
| 13 | JB3762-84 | Trailer socket | |
| 14 | 300-6.48.019-1 | License light (EC) | |
| 15 | 804-6.48.024 | Tail lamp | |
| 16 | 404-11.48.022/023 | Combination rear signal lamp | |
| 17 | 504G3.48A.104 | approach switch | |
| 18 | 504G3.48A.013 | Rear wiring harness | |
| 19 | 504G3.48.026 | Caution light swich | |
| 20 | 304G2-6.48.103 | Multi-function switch | |
| 21 | 504G3.48.022 | Pre-heating starting switch | |
| 22 | 504G3.48.105 | Starting scutcheon | |
| 23 | HX- SG102A | Flasher | |
| 24 | 354G3.48.021A | Combination meter | |
| 24 | 354G3.48.021 | Combination meter | |
| 24 | 504G3.48A.021A | Combination meter | |
| 24 | 504G3.48A.021 | Combination meter | |
| 25 | 1912 | Starting relay | |
| 26 | 504G3.48.101 | Oil level sensor | |
| 27 | JK231B | Brakelight switch | |
| 28 | 404-9.48.020 | Electrucity stop (Thailand) | |
| 29 | 504G3.48.102 | Water temperature sensor | |
| 30 | JFZ1511 | Generator | |
| 31 | 504G3.48.015 | Battery cable | |
| 32 | 404-11.48.020/021 | Head lamp | |
| 33 | DL125 | Electrucity horn | |
| 34 | 504G3.48A.011 | Front wiring harness |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
