Каталог запасных частей к технике: CASE IH STX-530 Steiger. SEAT - CUSHION ASSEMBLY
1
1
2
3
3
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
17
18
19
20
21
22
22
23
23
24
25
26
27
28
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 87553808 | 87553808 | SEAT ASSY | |
| 87553810 | 87553810 | SEAT ASSY | |
| 87553440 | 87553440 | SEAT ASSY | |
| 87553442 | 87553442 | SEAT ASSY | |
| 1 | 373476A1 | CUSHION | |
| 1 | 87395385 | CUSHION | |
| 1 | 87607884 | SEAT ACCESSORY | |
| 1 | 87397614 | CUSHION | |
| 2 | 87397613 | CUSHION | |
| 2 | 87395384 | CUSHION | |
| 2 | 87347893 | CUSHION | |
| 3 | 86994155 | ASSEMBLY | |
| 4 | 87416475 | KNOB | |
| 5 | 87590287 | SUPPORT | |
| 6 | 830-1110 | NUT | |
| 7 | 87300397 | SWITCH | |
| 8 | 87395388 | SWITCH | |
| 9 | 87395390 | HARNESS | |
| 10 | 87347956 | KIT | |
| 11 | 87308130 | SEAT BACK ADJUST. DEVICE | |
| 12 | 87037462 | SEAT BACK ADJUST. DEVICE | |
| 13 | 87347958 | KIT | |
| 14 | 87347944 | KIT | |
| 15 | 87395389 | CONTROL | |
| 16 | 302016A1 | PACKAGE | |
| 17 | 561-707 | SCREW | |
| 18 | 87347934 | LATCH | |
| 19 | 87347942 | KIT | |
| 20 | 87347941 | KIT | |
| 21 | 87347940 | KIT | |
| 22 | 86994165 | SEAT ACCESSORY | |
| 23 | 87347936 | KIT | |
| 24 | 87347939 | KIT | |
| 24 | 87397615 | ARMREST | |
| 24 | 87620258 | ARMREST | |
| 25 | 86400227 | SWITCH | |
| 26 | 86994172 | KIT | |
| 27 | 87626130 | HARNESS | |
| 28 | 87611650 | SWITCH |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
