Каталог запасных частей к технике: CASE IH MX-240 Magnum. TURBOCHARGER ASSEMBLY
1
1
1
2
3
4
5
6
7
8
9
10
11
11
12
12
13
14
15
16
17
18
19
20
20
21
22
22
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 86993017 | 86993017 | TURBOCHARGER | |
| J575169 | J575169 | KIT | |
| 87428460 | 87428460 | KIT | |
| 1 | NSS | NOT SERVICED SEPARATELY | |
| 1 | J538379 | HOUSING | |
| 1 | J535324 | HOUSING | |
| 2 | NSS | NOT SERVICED SEPARATELY | |
| 3 | NSS | NOT SERVICED SEPARATELY | |
| 4 | NSS | NOT SERVICED SEPARATELY | |
| 5 | NSS | NOT SERVICED SEPARATELY | |
| 6 | NSS | NOT SERVICED SEPARATELY | |
| 7 | NSS | NOT SERVICED SEPARATELY | |
| 8 | NSS | NOT SERVICED SEPARATELY | |
| 9 | NSS | NOT SERVICED SEPARATELY | |
| 10 | NSS | NOT SERVICED SEPARATELY | |
| 11 | NSS | NOT SERVICED SEPARATELY | |
| 12 | NSS | NOT SERVICED SEPARATELY | |
| 13 | NSS | NOT SERVICED SEPARATELY | |
| 14 | NSS | NOT SERVICED SEPARATELY | |
| 15 | NSS | NOT SERVICED SEPARATELY | |
| 16 | NSS | NOT SERVICED SEPARATELY | |
| 17 | J759917 | SET SCREW | |
| 18 | J535243 | GASKET | |
| 19 | J528010 | ADAPTER | |
| 20 | 614-8020 | BOLT | |
| 20 | J503533 | BOLT | |
| 21 | J533163 | RING | |
| 22 | J597308 | PLATE | |
| 22 | J534309 | PLATE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
