Каталог запасных частей к технике: ZF КПП ZF 16S151 (вар.). MAIN SHAFT
/5.gif)
10
40
50
90
90.110
90.120
90.130
90.140
90.150
90.160
90.170
90.180
90.190
90.200
90.210
90.220
90.230
140
150
160
180
200
210
220
260
270
270
270
270
270
270
270
270
270
270
270
270
270
280
300
320
330
350
370
370.10
370.20
370.30
370.30
370.50
370.60
390
410
410
420
430
430
440
460
460
460
460
460
460
460
460
460
480
500
500.10
500.10
500.10
500.10
500.10
500.10
500.20
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 1315.304.131 | Main shaft | |
| 40 | 0735.321.087 | Needle cage | |
| 50 | 1315.304.025 | Helical gear | |
| 90 | 1315.204.006 | Synchronizer | |
| 90.110 | 1312.304.106 | Диск сцепления ведомый | |
| 90.120 | 1268.304.424 | Кольцо внутреннее | |
| 90.130 | 1268.304.494 | Кольцо промежуточное | |
| 90.140 | 1268.304.525 | Кольцо внешнее | |
| 90.150 | 1312.304.158 | Synchrobody | |
| 90.160 | 1312.304.159 | COUPLING ELEMENT | |
| 90.170 | 1310.304.175 | Муфта скользящая | |
| 90.180 | 0732.040.409 | COMPRSPRING | |
| 90.190 | 1297.304.436 | PRESSURE PIECE | |
| 90.200 | 1268.304.525 | Кольцо внешнее | |
| 90.210 | 1268.304.494 | Кольцо промежуточное | |
| 90.220 | 1268.304.424 | Кольцо внутреннее | |
| 90.230 | 1312.304.106 | Диск сцепления ведомый | |
| 140 | 1313.304.038 | Bush | |
| 150 | 0750.115.325 | Needle cage | |
| 160 | 1315.304.004 | Helical gear | |
| 180 | 1315.304.018 | Clutch body | |
| 200 | 1315.304.132 | Bush | |
| 210 | 0750.115.324 | Needle cage | |
| 220 | 1315.304.006 | Helical gear | |
| 260 | 0750.117.677 | Tarollbearing | |
| 270 | 0630.501.316 | Retaining ring | |
| 270 | 0630.501.336 | Retaining ring | |
| 270 | 0630.501.315 | Retaining ring | |
| 270 | 0630.501.335 | Retaining ring | |
| 270 | 0630.501.314 | Retaining ring | |
| 270 | 0630.501.334 | Retaining ring | |
| 270 | 0630.501.313 | Retaining ring | |
| 270 | 0630.501.333 | Retaining ring | |
| 270 | 0630.501.312 | Retaining ring | |
| 270 | 0630.501.337 | Retaining ring | |
| 270 | 0630.501.338 | Retaining ring | |
| 270 | 0630.501.339 | Retaining ring | |
| 280 | 1315.332.073 | Pressure disc | |
| 300 | 1312.304.150 | Pipe | |
| 320 | 0735.321.087 | Needle cage | |
| 330 | 1315.304.027 | Helical gear | |
| 350 | 1316.304.190 | Clutch body | |
| 370 | 1356.204.006 | Synchronizer | |
| 370.10 | 1356.304.019 | Synchrobody | |
| 370.20 | 1356.304.023 | Sliding sleeve | |
| 370.30 | 1316.304.189 | Synchroring | |
| 370.50 | 1297.304.436 | PRESSURE PIECE | |
| 370.60 | 0732.040.409 | COMPRSPRING | |
| 390 | 1316.304.190 | Clutch body | |
| 410 | 0750.101.158 | Thrust washer | |
| 420 | 0750.119.125 | Internal ring | |
| 430 | 0750.115.534 | Roller cage | |
| 440 | 1315.304.089 | Helical gear | |
| 460 | 1315.304.048 | Axial washer | |
| 460 | 1315.304.047 | Axial washer | |
| 460 | 1315.304.046 | Axial washer | |
| 460 | 1315.304.045 | Axial washer | |
| 460 | 1315.304.044 | Axial washer | |
| 460 | 1315.304.043 | Axial washer | |
| 460 | 1315.304.085 | Axial washer | |
| 460 | 1315.304.086 | Axial washer | |
| 480 | 0750.117.232 | Конический роликоподшипник | |
| 500 | 1312.204.040 | Split ring | |
| 500.10 | 0730.107.023 | Split ring | |
| 500.10 | 0730.107.022 | Split ring | |
| 500.10 | 0730.107.021 | Split ring | |
| 500.10 | 0730.107.020 | Split ring | |
| 500.10 | 0730.107.019 | Split ring | |
| 500.20 | 0730.062.781 | Retaining ring |
