Каталог запасных частей к технике: YTO LR4M5-T73EXA-U2. Gear Train Assy
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | GB/21 | Bolt | |
| 2 | RT060026-1D | Thrust plate, hydraulic pump gear | |
| 3 | GB/T93 | Spring washer 8 | |
| 4 | GB/T894.1 | Retaining ring 30 | |
| 5 | RT.060025B2 | Driving splined sleeve, hydraulic pump | |
| 6 | GB/T895.2 | Retaining ring 30 | |
| 7 | R.060004 | Camshaft gear clamp | |
| 8 | GB21 | Bolt M10x20-8.8-Zn.D | |
| 9 | GB22 | Bolt M10x85-8.8-Zn.D | |
| 10 | R.060031-1 | Locking washer | |
| 11 | R.060011 | Thrust plate, idle gear | |
| 12 | GB21 | Bolt M10x20-8.8-Zn.D | |
| 13 | GB/T93 | Spring washer 8 | |
| 14 | LRQ.060007 | Retaining plate, injection pump gear | |
| 15 | 4RHZQ.060002 | Driving gear, oil pump | |
| 16 | LR.060005C | Injection pump gear | |
| 17 | R.060100B | Idle gear assy | |
| 18 | R.060003B | Camshaft gear | |
| 19 | LR.060001B | Crankshaft gear | |
| 20 | RT.061100D | Hydraulic pump gear assy | |
| 21 | R.060021A | Air compressor gear | |
| 22 | R.060023-1 | Screw, lubrication oil passage M8x38-8.8-Zn.D | |
| 23 | GB/T93 | Spring washer 8 | |
| 24 | GB21 | Bolt M10x20-8.8-Zn.D | |
| 25 | RT060022 | Screw, lubrication oil passage M8x25-8.8-Zn.D | |
| 26 | R.060012 | Screw, lubrication oil passage M10x40-8.8-Zn.D | |
| 27 | R.060023-1 | Screw, lubrication oil passage M8x38-8.8-Zn.D | |
| 28 | RT.060009 | Oil pipe assy, timing gear | |
| 29 | R.060009 | Shaft, idle gear | |
| 30 | RT.060019-1 | Sealing ring | |
| 31 | RT.060027 | Plug | |
| 32 | LRT.060024-3 | Driving gear shaft, hydraulic pump | |
| 33 | LRT.060029 | Gasket, hydraulic pump | |
| 34 | RT.060028 | Hydraulic pump cover | |
| 35 | GB21 | Bolt M10x20-8.8-Zn.D |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
