Каталог запасных частей к технике: HOWO MC11. OIL PAN
1.1
1.2
1.3
2
3.1
3.2
3.3
3.4
4
5
6
7
8
9
10
11
12
13.1
13.2
13.3
13.4
13.5
14
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 201V05800-6370 | 201V05800-6370 | Oil pan | |
| 1.1 | 201V05801-5741 | Oil pan component | |
| 1.2 | MQ6-56631-0110 | Gasket | |
| 1.3 | MQ6-08042-0207 | Screw Plug | |
| 2 | MQ6-03216-8310 | Hexagon head bolt | |
| 3.1 | 200V05840-0126 | Oil pan support | |
| 3.2 | 200V05840-0139 | Oil pan support | |
| 3.3 | 200V05840-0128 | Oil pan support | |
| 3.4 | 200V05840-0129 | Oil pan support | |
| 4 | 200V05904-0212 | Oil pan gasket | |
| 5 | MQ6-03216-8204 | Hex Bolt | |
| 6 | 200V05103-5036 | Oil pump cover | |
| 7 | MQ6-02191-0511 | Hexagon socket head cap screws | |
| 8 | MQ6-56936-1150 | O-ring | |
| 9 | 200V05105-5000 | Internal oil pump rotor shaft | |
| 10 | 200V05104-0234 | Oil pump inner rotor | |
| 11 | 200V05104-0251 | Oil pump outer rotor | |
| 12 | MQ6-56333-3363 | O-ring | |
| 13 | 200V05701-6055 | Suction pipe assembly | |
| 13.1 | 200V05703-5364 | Suction tube assembly | |
| 13.2 | MQ6-03216-8305 | Hex bolt | |
| 13.3 | 200V90710-0080 | washer | |
| 13.4 | 200V05740-0174 | Suction pipe bracket | |
| 13.5 | MQ6-11240-0404 | Hexagon nuts | |
| 14 | MQ6-03216-8303 | Hex Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
