Каталог запасных частей к технике: DCEC ISZ450 41. Cylinder

C3681054

C3903112

C3903112

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

20

21

22

23

24

25

26

27

28

29

Позиция на иллюстрации	Заводской номер детали		Название детали
C3681054	C3681054		DOWEL, PIN
C3903112	C3903112		SCREW, HEX FLANGE HEAD CA
C3903112	C3903112		SCREW, HEX FLANGE HEAD CA
1	2869805		BEARING, CRANKSHAFT THRUS
2	C2869983		LEVER, CAM FOLLOWER
3	C2870121		SEAL, FRONT COVER
4	C2874044		CARRIER, SEAL
5	C2874066		BLOCK, CYLINDER
6	C2869839		BUSHING
7	C2873989		SCREW, FRACTURE RESISTANT
8	C2884751		CAP, MAIN BEARING
9	C2884752		CAP, MAIN BEARING
10	C3007632		PLUG, EXPANSION
11	C3015865		PLUG, EXPANSION
12	C2883240		STIFFENER, CYLINDER BLOCK
13	C2884766		COVER, FRONT
14	C3100706		DOWEL, RING
15	C3681054		DOWEL, PIN
16	C3681054		DOWEL, PIN
17	C3685173		SEAL, OIL
18	C3900720		DOWEL, RING
19	C3901846		DOWEL, PIN
20	C3903112		SCREW, HEX FLANGE HEAD CA
21	C3903112		SCREW, HEX FLANGE HEAD CA
22	C3903112		SCREW, HEX FLANGE HEAD CA
23	C4316828		CRANKSHAFT, ENGINE
24	C4327640		GEAR, CRANKSHAFT
25	C4960053		SEAL, FRONT COVER
26	C4999939		BEARING, MAIN
27	C4999940		BEARING, MAIN
28	C4999962		LINER, CYLINDER
29	D2873961		SEAL, O RING
