Каталог запасных частей к технике: Cummins Серия ISMe. FP2953-03 Fuel Pump
/34.gif)
1
2
3
4
5
6
7
8
9
10
11
11
11
12
13
14
15
16
17
18
18
19
20
21
22
23
24
25
26
27
28
29
30
31
31
31
31
32
32
32
32
33
34
35
36
37
37
37
38
39
40
41
42
43
44
45
46
47
48
48
49
50
51
52
53
54
55
56
57
58
59
60
61
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| FP2953-03 | FP2953-03 | Fuel Pump | |
| 3090996 | 3090996 | Support, Fuel Pump | |
| 3074317 | 3074317 | Spacer, Seal | |
| 3074316 | 3074316 | Spacer, Seal | |
| 3040813 | 3040813 | Plug, Threaded | |
| 3037537 | 3037537 | Seal, O Ring | |
| 128807 | 128807 | Ring, Retaining | |
| 3037536 | 3037536 | Plug, Threaded | |
| 3408421 | 3408421 | Solenoid | |
| 4903125 | 4903125 | Gear & Shaft | |
| 3033742 | 3033742 | Plug, Threaded | |
| 4954880 | 4954880 | Pump, Gear Fuel | |
| 3056416 | 3056416 | Plug, Threaded | |
| 3096077 | 3096077 | Gasket, Fuel Pump | |
| 3071643 | 3071643 | Seal, Oil | |
| 3417674 | 3417674 | Pump, Fuel | |
| ВМ76340 | ВМ76340 | Damper, Fuel Pump | |
| 3042619 | 3042619 | Nipple, Coupling | |
| 3037536 | 3037536 | Plug, Threaded | |
| 3084713 | 3084713 | Seal, Oil | |
| 129888 | 129888 | Seal, Rectangular Ring | |
| 1 | 100099 | Seal, Rectangular Ring | |
| 2 | 139988 | Seal, Rectangular Ring | |
| 3 | 153336 | Body, Fuel Pump Damper | |
| 4 | 153338 | Cover, Fuel Pump Damper | |
| 5 | 160514 | Washer, Plain | |
| 6 | 202897 | Diaphragm, Ful Pump Damper | |
| 7 | 3017051 | Screw, Captive Washer Cap | |
| 8 | 70704 | Washer, Plain | |
| 9 | 151900 | Seal, Rectangular Ring | |
| 10 | 153346 | Screw, Socket Head Cap | |
| 11 | 181466 | Washer, Lock | |
| 12 | S2286 | Screw, Drive | |
| 13 | 70700 | Spring, Compression | |
| 14 | 100129 | Screw, Socket Head Cap | |
| 15 | 105375 | Nameplate | |
| 16 | 129768 | Spring, Valve | |
| 17 | 129839 | Shield, Shutoff Valve | |
| 18 | 129888 | Seal, Rectangular Ring | |
| 19 | 146483 | Screen, Filter | |
| 20 | 196057 | Disc, Valve | |
| 21 | 3014575 | Cap, Fuel Pump Filter | |
| 22 | 3021123 | Seal, O Ring | |
| 23 | 3079584 | Plug, Threaded | |
| 24 | 3034412 | Seal, О Ring | |
| 25 | 3034451 | Housing, Actuator | |
| 26 | 3095355 | Hub, Jaw Coupling | |
| 27 | 3042620 | Nipple, Coupling | |
| 28 | 3037537 | Seal, O Ring | |
| 29 | 3408421 | Solenoid | |
| 30 | 3056009 | Disc, Actuator | |
| 31 | 3056003 | Plug, Threaded | |
| 32 | 3056415 | Seal, О Ring | |
| 33 | 3065944 | Screw, Captive Washer Cap | |
| 34 | 3068768 | Ring, Retaining | |
| 35 | 64816А | Dowel, Pin | |
| 36 | 110855 | Gasket, Fuel Pump | |
| 37 | 4903124 | Gear, Fuel Pumping | |
| 38 | 175865 | Shaft, Fuel Pump | |
| 39 | 3033719 | Dowel, Ring | |
| 40 | 4010038 | Valve, Check | |
| 41 | 4010514 | Tube, Fuel Drain | |
| 42 | 68139 | Колено входящей в другую деталь соединительной части | |
| 43 | 3034412 | Seal, О Ring | |
| 44 | 4010297 | Spring, Compression | |
| 45 | 4010296 | Plunger, Prs Regulator | |
| 46 | 3085615 | Ring, Retaining | |
| 47 | 3033714 | Housing, Fuel Pump Gear | |
| 48 | 3033724 | Bushing | |
| 49 | 4954876 | Cover, Fuel Pump Gear | |
| 50 | 3095356 | Shaft, Fuel Pump Drive | |
| 51 | 128807 | Ring, Retaining | |
| 52 | 3096077 | Gasket, Fuel Pump | |
| 53 | 3074317 | Spacer, Seal | |
| 54 | 3074316 | Spacer, Seal | |
| 55 | 3090996 | Support, Fuel Pump | |
| 56 | 3084713 | Seal, Oil | |
| 57 | 3071643 | Seal, Oil | |
| 58 | 3040813 | Plug, Threaded | |
| 59 | 3037537 | Seal, O Ring | |
| 60 | 3100526 | Union, Male | |
| 61 | 3037236 | Seal, O'Ring |
