Каталог запасных частей к технике: Cummins QSX-15 I. RL1732 Rocker Lever
1
1
1
1
1
1
1
1
1
1
2
2
3
3
3
3
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
11
11
12
12
13
14
14
15
15
15
15
15
15
16
16
16
16
16
1
1
1
1
1
1
1
1
1
1
17
17
17
17
18
20
20
20
20
3
3
3
3
3
3
15
15
15
15
15
15
16
16
16
16
16
1
1
1
1
1
1
1
1
1
1
17
17
17
17
19
19
19
19
20
20
20
20
3
3
3
3
3
3
21
22
22
23
23
23
15
15
15
15
15
15
16
16
16
16
16
1
1
1
1
1
1
1
1
1
1
17
17
17
17
24
19
19
19
19
20
20
20
20
3
3
3
3
3
3
15
15
15
15
15
15
16
16
16
16
16
1
1
1
1
1
1
1
1
1
1
17
17
17
17
19
19
19
19
20
20
20
20
3
3
3
3
3
3
25
23
23
23
27
27
27
27
28
28
28
28
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 3100776 | 3100776 | Lever, Rocker | |
| 3100777 | 3100777 | Lever, Rocker | |
| 1 | 3067941 | Plug, Ball | |
| 2 | 3100778 | Roller, Cam Follower | |
| 3 | 3679504 | Pin, Roll | |
| 4 | 3679869 | Pin, Cam Follower Roller | |
| 5 | 3679870 | Bushing | |
| 6 | 3680167 | Lever, Rocker | |
| 7 | 3680057 | Nut, Regular Hexagon Jam | |
| 8 | 3680058 | Screw, Rkr Lever Adjusting | |
| 3679418 | 3679418 | Shaft, Rocker Lever | |
| 9 | 3417768 | Plug, Drive | |
| 10 | 3679417 | Shaft, Rocker Lever | |
| 11 | 4059197 | Spacer, Thrust Ring | |
| 12 | 3679427 | Clamp, Retaining | |
| 13 | 3680732 | Plug, Expansion | |
| 14 | 3679561 | Spacer, Thrust Ring | |
| 4059410 | 4059410 | Lever, Rocker | |
| 15 | 4059377 | Screw, Rkr Lever Adjusting | |
| 16 | 3679694 | Nut, Regular Hexagon Jam | |
| 4659295 | 4659295 | Lever, Rocker | |
| 1 | 3067941 | Plug, Ball | |
| 17 | 4059322 | Roller, Cam Follower | |
| 18 | 4059294 | Lever, Rocker | |
| i9 | 4026779 | Pin, Cam Follower Roller | |
| 20 | 4059282 | Bushing | |
| 3 | 3679504 | Pin, Roll | |
| 4059412 | 4059412 | Lever, Rocker | |
| 15 | 4059377 | Screw, Rkr Lever Adjusting | |
| 16 | 3679694 | Nut, Regular Hexagon Jam | |
| 4059352 | 4059352 | Lever, Rocker | |
| 1 | 3067941 | Plug, Ball | |
| 17 | 4059322 | Roller, Cam Follower | |
| 19 | 4026780 | Pin, Cam Follower Roller | |
| 20 | 4059282 | Bushing | |
| 3 | 3679504 | Pin, Roll | |
| 21 | 4059351 | Lever, Rocker | |
| 4059283 | 4059283 | Shaft, Rocker Lever | |
| 22 | 4059284 | Shaft, Rocker Lever | |
| 23 | 3680954 | Plug, Drive | |
| 4059411 | 4059411 | Lever, Rocker | |
| 15 | 4059377 | Screw, Rkr Lever Adjusting | |
| 16 | 3679694 | Nut, Regular Hexagon Jam | |
| 4059298 | 4059298 | Lever, Rocker | |
| 1 | 3067941 | Plug, Ball | |
| 17 | 4059322 | Roller, Cam Follower | |
| 24 | 4059297 | Lever, Rocker | |
| 19 | 4026780 | Pin, Cam Follower Roller | |
| 20 | 4059282 | Bushing | |
| 3 | 3679504 | Pin, Roll | |
| 4059413 | 4059413 | Lever, Rocker | |
| 15 | 4059377 | Screw, Rkr Lever Adjusting | |
| 16 | 3679694 | Nut, Regular Hexagon Jam | |
| 4059354 | 4059354 | Lever, Rocker | |
| 1 | 3067941 | Plug, Ball | |
| 17 | 4059322 | Roller, Cam Follower | |
| 19 | 4026779 | Pin, Cam Follower Roller | |
| 20 | 4059282 | Bushing | |
| 3 | 3679504 | Pin, Roll | |
| 25 | 4059353 | Lever, Rocker | |
| 4059288 | 4059288 | Shaft, Rocker Lever | |
| 26 | 4059289 | Shaft, Rocker Lever | |
| 23 | 3680954 | Plug, Drive | |
| 27 | 3681221 | Screw, Hex Flange Head Cap | |
| 28 | 4059342 | Crosshead, Valve |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
