Каталог запасных частей к технике: Cummins QSNT-G. PUMP, WATER WP 1780
1
2
3
4
5
6
7
8
8
8
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
21
22
23
24
25
26
27
28
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4915398 | 4915398 | PUMP, WATER | |
| 4296121 | 4296121 | PULLEY, WATER PUMP | |
| 4914636 | 4914636 | PULLEY, IDLER | |
| 1 | 182706 | SCREW, HEXAGON HEAD | |
| 2 | 217638 | BELT, V RIBBED | |
| 3 | 3012468 | SCREW, CAPTIVE WAS | |
| 4 | 3012469 | SCREW, CAPTIVE WAS | |
| 5 | 3076522 | GASKET, WATER PUMP | |
| 6 | S 201 | NUT, HEAVY HEXAGON | |
| 7 | S 965 E | PLUG, PIPE | |
| 8 | S 16255 | RING, RETAINING | |
| 8 | S 16255 | RING, RETAINING | |
| 9 | 145506 | SAEL, O RING | |
| 10 | 213082 | WASHER, PLAIN | |
| 11 | 215397 | PULLEY, IDLER | |
| 12 | 3038998 | SEAL, OIL | |
| 13 | 3063246 | BEARING, BALL | |
| 14 | 4914655 | SHAFT, IDLER | |
| 15 | 4914656 | SPACER, MOUNTING | |
| 16 | S 911 B | PLUG, PIPE | |
| 17 | 112302 | RING, RETAINING | |
| 18 | 196844 | SPACER, BEARING | |
| 19 | 3000888 | IMPELLER, WATER PUMP | |
| 20 | 3014241 | INSERT, IMPELLER | |
| 21 | 3010150 | BEARING, IDLER BALL | |
| 22 | 3013786 | PLUG, PIPE | |
| 23 | 3038997 | SEAL, OIL | |
| 24 | 4060899 | SEAL, WATER PUMP | |
| 25 | 4296120 | SHAFT, WATER PUMP | |
| 26 | 203097 | SLEEVE, WEAR | |
| 27 | 3025861 | PULLEY, WATER PUMP | |
| 28 | 4296123 | BODY, WATER PUMP |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
